Conversion to a Pull Push Saw

When operating as a pull push saw, the saw
blade must be able to run freely over the com-
plete cutting length.
– To release the saw blade, push lever

25

 to-

ward the left.

Sawing with Sliding Action (see figure Q)

– Adjust the desired mitre angle on the univer-

sal guide

1

. (see “Adjusting Mitre Angles”,

page 46)

Note:

To avoid jamming or slipping of the

workpiece, the clearance between saw blade

28

 and fence

36

may not exceed 15 mm

(max.)

.

– Adjust the desired bevel angle. (see “Adjust-

ing Bevel Angles”, page 47)

– Position the workpiece on the saw table in

front of the blade guard

3

.

– Align your mark on the workpiece along the

laser beam. (see “Marking the Cutting Line”,
page 47)

– Raise or lower the saw blade with the crank

18

 so that the upper saw teeth project ap-

prox. 5 mm above the workpiece surface.

– Adjust the blade guard according to the

workpiece height.
When sawing, the blade guard must always
face lightly against the workpiece.

– Hold the workpiece and press it firmly

against the fence.

– Switch on the machine.
– Actuate release lever

24

 and pull the pull

handle

23

 with uniform feed toward the

front, so that the saw blade cuts through the
workpiece.

– Release the pull handle.

The saw blade returns to the starting posi-
tion.

– Switch off the machine and wait until the

saw blade has come to a complete stop.

Sawing

Operation as a Table Saw

When using as a table saw, move the workpiece
toward the rear against the stationary saw
blade.
This operating mode is suitable for:
– Lengthwise cuts
– Cutting lengths in excess of 212 mm

Conversion to a Table Saw (see figure R)

When operating as a table saw, the saw blade
must be locked in the centre of the saw table.
– Pull the release lever

24

 and the pull handle

23

 toward the front and at the same time,

push lever

25

 toward the right to lock the

saw blade until it engages.

Sawing

– Adjust the desired bevel angle. (see “Adjust-

ing Bevel Angles”, page 47)

– Adjust a 0 °  mitre angle. (see “Adjusting Mitre

Angles”, page 46)

– Depending on the workpiece size and on the

set bevel angle, mount the fence

36

upright

or flat

 to the universal guide

1

. (see “Mount-

ing the Fence to the Universal Guide”,
page 44)

Note:

When sawing, workpieces can become

jammed between the universal guide and the
saw blade, be caught by the rotating saw
blade, and be thrown from the machine.
Therefore, adjust the fence

36

 in such a man-

ner that its guiding end ends in the area be-
tween the saw blade centre and the riving
knife.
For this, loosen wing bolt

34

, move the fence

and retighten the wing bolt again.

– Position the workpiece on the saw table in

front of the blade guard

3

.

– Align your mark on the workpiece along the

laser beam. (see “Marking the Cutting Line”,
page 47)

– Raise or lower the saw blade with the crank

18

 so that the upper saw teeth project ap-

prox. 5 mm above the workpiece surface.
