Guide rail for the universal guide

32

Detent override for adjustment of mitre
angles

33

Wing bolt for locking mitre angles

34

Wing bolt for locking the fence

36

35

Angle stop with scale for mitre angles

36

Fence on the universal guide

37

Wing bolt for locking the guide rail

31

38

Rotary knob for locking the universal guide

39

Bottom plate

40

Battery lid

41

Laser unit

42

Fastening kit for “laser unit”

43

Fastening kit for “blade guard”

44

Laser on/off switch (for marking of cutting
line)

45

Fastening screw for laser housing

46

Laser housing

47

Thumbwheel for positioning of laser
(flush alignment)

48

Fastening kit for “table extension”

49

Support leg of the table extension

50

Allen screws of the upper fastening plate for
support leg

49

51

Rotary knob for fine adjustment of the table-
extension height

52

Rotary knob for locking the table extension

53

Support tongue for the fence

36

54

Lower saw blade cover

55

Cleaning flap of the lower saw blade cover

56

Spindle lock

57

Allen screw (size 6 mm) for mounting of saw
blade

58

Exterior clamping flange

59

Interior clamping flange

60

Screws for fastening of the riving knife

Accessories shown or described are not part of the
standard delivery scope of the product. A complete
overview of accessories can be found in our acces-
sories program.

Technical Data

Noise Information

Measured sound values determined according
to EN 61029.
Typically the A-weighted noise levels of the
product are: Sound pressure level 97 dB(A);
Sound power level 110 dB(A). Uncertainty
K = 3 dB.

Wear hearing protection!

Pull Push Saw

PPS 7S

Article number

3 603 M03 3..

Rated power input

W

1400

No-load speed

min

-1

4800

Reduced starting
current

z

Constant electronic
control

z

Laser type

nm

mW

650

< 0.39

Laser class

1M

Weight according to
EPTA-Procedure
01/2003

kg

23.2

Protection class

/

II

Maximum workpiece dimensions, see page 49.

The values given are valid for a nominal voltage [U] of
230 V. For different voltages and models for specific
countries, these values can vary.

Please observe the article number on the type plate of
your machine. The trade names of the individual ma-
chines may vary.

Dimension of suitable saw blades

Saw blade diameter

mm

190

Blade body thickness

mm 1.6 – 2.0

Tooth thickness/setting, min.

mm

2.6

Mounting hole diameter

mm

30
