44

 | English

1 609 929 W71 | (30.3.11)

Bosch Power Tools

Adjusting the Flush Levelling:

 (see figure C2)

– Turn thumbwheel

47

 until the parallel laser

beam is flush to the desired cutting-line mark
over the complete length.

One rotation in anticlockwise direction moves
the laser beam from left to right; one rotation in
clockwise direction moves the laser beam from
right to left.

Mounting the Table Extension and the

Fences/Stops

Mounting the Table Extension (see figure D)

The table extension

27

 is used to widen or ex-

tend the saw table

7

. It can be mounted either

on the left or right side, or to the rear of the saw
table.
For assembly, use the fastening kit for the “table
extension”

48

. (rotary knob

52

, socket bolt, nut)

– Slide or insert the table extension

27

 into the

desired guide groove

8

 of the saw table.

When the table extension is mounted left or
right from the saw table, it is supported toward
the front.
When the table extension is mounted to the rear
of the saw table, it can be supported toward the
left or the right.
– Move the table extension until the lower

holding prongs of the support leg

49

 are

aligned with one of the mounting holes

9

.

If required, move the upper fastening plate of
the support leg

49

.

For this, loosen both Allen screws

50

 with Al-

len key

13

, move the upper fastening plate

until the support leg

49

 is aligned with the

desired mounting hole

9

, and retighten the

Allen screws

50

 again.

– Place the nut into the mounting hole

9

 and

screw the holding prongs of the support leg
to the saw table with the socket bolt.

– Screw rotary knob

52

 for locking the table ex-

tension into the bolt hole intended for it, and
tighten it.

The table extension must be flush with the saw
table surface.
– Adjust the correct height of the table exten-

sion

27

 with rotary knob

51

.

Mounting the Universal Guide (see figure E)

The universal guide

1

 can be mounted left or

right on the saw table

7

, or to the table exten-

sion

27

.

Note:

When sawing bevel angles, the universal

guide should be mounted to the

right of the saw

blade

.

– Slide or insert the extension plate

30

 of the

universal guide into the desired guide groove

8

 of the saw table or into the guide groove of

the table extension

27

.

– Screw  rotary  knob

38

 for locking the univer-

sal guide into the bolt hole intended for it,
and tighten it.

Mounting the Fence to the Universal Guide

The fence

36

 of the universal guide is used as a

supporting surface for the workpiece.

When sawing narrow workpieces

, the fence

36

should be mounted flush to universal guide

1

 in

order to prevent jamming or slipping of the
workpiece. (see figure F1)

When sawing high workpieces and when saw-
ing with slide action

, the fence

36

 should be

mounted upright to the universal guide

1

, so

that the supporting surface of the workpiece is
as large as possible. (see figure F2)
– Loosen wing bolt

34

.

– Slide the fence

36

 either upright or flat onto

the guide tongue

53

 of the universal guide.

– Tighten wing bolt

34

 again.

Mounting to a Working Surface

(see figure G)

f

To ensure safe handling, the machine must
be mounted on a level and stable surface
(e. g., workbench) prior to using.

– Fasten the power tool with suitable screw

fasteners to the working surface. The mount-
ing holes

9

 serve for this purpose.
