Product Description and
Specifications

Read all safety warnings and all instruc-
tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire
and/or serious injury.

Intended Use

The power tool is intended as a stationary machine for making
straight lengthways and crossways cuts in wood. In this, hori-
zontal mitre angles from – 52 ° to +60 ° as well as vertical bevel
angles from 47 ° (leftward) to 47 ° (rightward) are possible.
The capacity of the power tool is designed for sawing hard-
wood and softwood, as well as particle and fibre board.
When using appropriate saw blades, sawing aluminium pro-
files and plastic is also possible.

Product Features

The numbering of the components shown refers to the repre-
sentation of the power tool on the graphic pages.

1

Dust bag

2

Extraction adapter

3

Laser warning label

4

Handle

5

Locking lever

6

Blade guard

7

Transport handle

8

Retracting blade guard

9

Fence extension

10

Fence

11

Saw-table extension

12

Mounting holes

13

Insert plate

14

Mitre detent override

15

Locking knob for various mitre angles

16

Mitre detent lever

17

Bevel lock lever

18

Detents for standard mitre angles

19

Recessed handles

20

Hex key (6 mm/4 mm)

21

Hex key (2 mm)

22

Material clamp

23

Roller

24

Right bevel angle indicator  (0 ° to 47 °)

25

Chip deflector

26

Glide mechanism lock lever

27

Laser protection cap

28

Glide arm

29

Adjusting screw of depth stop

30

Depth stop

31

Transport safety-lock

32

Scale for bevel angle

33

Left bevel angle indicator  (47 ° to 0 °)

34

Adjustment knob for 22.5 ° bevel angle

35

Lock screw of the material stop

36

Material stop

37

Scale for mitre angle

38

Saw table

39

Rotary knob for adjustment of the bevel angle range

40

Saw blade

41

Chip ejector

42

Locking screw of linkage

43

43

Linkage of the retracting blade guard

44

Front fastening screw (cover plate/retracting blade guard)

45

Rear fastening screw (cover plate/retracting blade guard)

46

Cover plate

47

Spindle lock

48

Hex socket screw (size 6 mm) for mounting of saw blade

49

Clamping flange

50

Interior clamping flange

51

Clamping lever of the saw-table extension

52

Clamping lever of the adjustable fence

53

Cover plate tab

54

Glide movement controller

55

Set screws for damping

56

Mounting holes for material clamp

57

Wing bolt

58

Threaded rod

59

Mitre angle indicator

60

On/Off switch

61

Laser on/off switch (for marking of cutting line)

62

Screws for insert plate

63

Clamping screw of the material stop

64

Adjustment screw for laser position (flush levelling)

65

Screws for laser protection cap

66

Fastening screw for laser mounting plate

67

Fastening screw for laser housing

68

–

70

Set screws for 0 ° basic setting (bevel angle)

71

Set screw for 45 ° basic setting (leftward bevel angle)

72

Set screw for 45 ° basic setting (rightward bevel angle)

73

Set screws of scale

37

 for mitre angles

74

Screw for mitre angle indicator

75

Set screw for clamping force of lock lever

17

76

Velcro strap

Accessories shown or described are not part of the standard deliv-
ery scope of the product. A complete overview of accessories can
be found in our accessories program.
