 Turning on/off the power

 Turning on the power:
 While the recorder is turned off,
slide the  POWER/HOLD  switch to
the direction of the arrow.

 Memory  card

 This recorder uses two types of
memory cards: a microSD card
as internal memory, and an SD
card as additional memory.
 You can remove the content recorded
in both the cards safely in case of
malfunction of the recorder.

 Compatible  cards

 The recorder supports memory card
capacity from 512 MB up to 32 GB.

 Cards  compatibility

 For a list of card compatible with the
recorder, please visit the product
homepage at the Olympus website

 Card  recognition

 After inserting SD card, the message
[

Please Wait

 ] will flash on the display

while the recorder recognizes the
SD card.

 Detecting abnormal voltage:

 If the recorder detects a DC power
voltage outside the allowed voltage
range (4.4-5.5V ), then [

Power

Supply Error Remove Power Plug

 ]

will appear on the display, and all
operation will stop. The recorder will
not be operable if abnormal voltage
is detected. Use an AC adapter
compatible with the voltage standard
of your environment (optional).

 Turning off the power:
 Slide the  POWER/HOLD  switch to
the direction of the arrow, and hold
it for 0.5 seconds or longer.

applicable to your region or contact
your Olympus reseller where you
purchased the product.

 Notes:

 •

When initializing (formatting) a
card, confirm that no necessary
data is stored on the memory
card beforehand. Initialization
completely erases the existing
data on the card.

 •  Cards formatted (initialized) by

another device, like a computer,
may not be recognized. Be sure
to format them with this recorder
before use.

 •  The card has a service life. When

reaching the end of its life, writing
or erasing data on the card will be
disabled. In this case, replace the
card.

 •  If you use a PC card adapter

compatible with the card to save
or delete some data on the card,
the maximum recording time on
the card may be decreased. To
recover the original recording time,
initialize/format the card in the
recorder.

 Inserting and ejecting a SD card

 Inserting a SD card:

 Insert the SD card fully into the card
slot with the card facing the direction
shown in the illustration below, until
it clicks into place.

 •

Insert the card keeping it straight.

 HOLD

 If you set the recorder to HOLD
mode, the running conditions will
be preserved, and all buttons will be
disabled.

 Set the recorder to HOLD mode:
 Slide the  POWER/HOLD  switch to
the [ HOLD ] position.

 After the recorder is set to HOLD
mode, the [

Hold

 ] message will be

displayed.

 Exit HOLD mode:
 Slide the  POWER/HOLD  switch to
the

A

   position.

A

 Notes:

 •  If any button is pressed during

HOLD mode, the clock will be
displayed for 2 seconds, but the
recorder will not be operable.

 •  If HOLD mode is entered during

playback or recording mode, the
recorder will not be operable
but the playback/recording will
continue ( When playback has
ended or the recording has ended
due to the remaining memory
being used up, it will stop).
