 Inserting the battery

 This recorder uses a lithium ion
battery specified by Olympus (LI-42B).
Do not use any other type of battery.

1

 Lightly press down on the battery
cover release button, then open
the battery cover, as shown in the
illustration below.

1

2

3

2

   Insert the battery observing the

correct polarity as shown in the
illustration, then close the battery
cover.

 •  Insert the battery by sliding in

direction

A

  while pushing down

in direction

B

 .

 Battery  indicator:

 The battery indicator on the display
will decrease as the battery loses
power.

 •  When this [

] indicator appears

on the display, charge the battery
as soon as possible. When the
battery is too weak, [

s

 ]  and

[

Battery Low

 ] will appear on the

display and the recorder will shut
down.

 Notes:

 •  Turn off the recorder before

removing the battery. Removing
the battery while the recorder is still
in use may cause malfunctions, file
corruption or file loss.

 •  Remove the battery if you are not

going to use the recorder for an
extended period of time.

 Charging the battery

 Fully charge the battery (approx. 2
hours 30 minutes) before use.

 Connect the USB cable to the
recorder.

 Notes:

 •  Charge the battery frequently

during the first period of use. The
battery will perform better after
several charge/discharge cycles.

 •  Models of batteries which are

different from the included one may
not be charged.

 •  Charging the battery via the USB

cable connection may not be
successful depending on the power
capacity of the USB port in your
PC. Use the AC adapter (optional)
instead.

 •  Do not charge the recorder through

a USB hub.

 •  Do not attach or remove the battery

if the USB cable is connected.

 Using the lithium ion battery

 The included battery is exclusively for
use with the Olympus voice recorder
DS-3500. Do not use in combination
with other electronic equipment.

 Cautions concerning the battery:

 Read the following instructions
carefully when you use the battery.

 Discharging:

 Rechargeable batteries self-discharge
while not in use. Charge it regularly
before use.

 Battery  life:

 Over time, the rechargeable battery
may gradually wear down. When
the operating time becomes shorter
even if the rechargeable battery is
fully charged under the specified
condition, replace it with a new one.

 Operating  temperature:

 Rechargeable batteries are chemical
products. Battery efficiency may vary
even when operating within the
recommended temperature range.
 This is an inherent nature of these
products.

 Recommended temperature range
of use:

During operation:

   0°C - 42°C


Charging:

   5°C - 35°C


Storage for a long period:

   –20°C - 60°C
 Using the battery outside the above
temperature range may result in
declining efficiency and shorter
battery life.

 Notes:

 •  When disposing the batteries,

always observe the local laws and
regulations. Contact your local
recycling center for proper disposal
methods.

 •  If battery is not fully discharged,

protect it against short-circuiting
(e.g. by taping the contacts) before
disposal.

 For customers in Germany:

 Olympus has a contract with the GRS
(Joint Battery Disposal Association) in
Germany to ensure environmentally
friendly disposal.

 Power supply from USB cable

 Use the USB cable when recording for
extended period of time.

1

 Verify that the recorder is in stop
mode.

2

 Connect the USB cable to the
recorder while pressing the


OK/MENU

   button.

 •  After removing the battery, it may

become necessary to re-set the
time and date if you leave the
battery out of the recorder for more
than 15 minutes or if you remove
the battery right after loading it into
the recorder.
