 | English

The measuring tool is suitable for indoor and outdoor use.

Product Features

The numbering of the product features shown refers to the il-
lustration of the measuring tool on the graphic page.

(1)

Laser beam outlet aperture

(2)

Battery indicator

(3)

Button for laser operating mode

(4)

On/off switch

(5)

1/4" tripod mount

(6)

Guide groove

(7)

Battery compartment cover locking mechanism

(8)

Battery compartment cover

(9)

Laser warning label

(10)

Serial number

(11)

Rotating mount (RM 10)

a)

(12)

Guide rail

(13)

Fastening slot

(14)

Fine adjustment screw of the rotating mount

(15)

Magnet

(16)

Ceiling clip (DK 10)

a)

(17)

Universal holder (BM 1)

a)

(18)

Holder (LB 10)

a)

(19)

Laser receiver

a)

(20)

Laser target plate

a)

(21)

Tripod (BT 150)

a)

(22)

Telescopic shaft (BT 350)

a)

(23)

Laser goggles

a)

(24)

Protective bag

a)

a)

Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.

Technical Data

Point and line laser

GCL 2-50 G

Article number

3 601 K66 M..

Working range

A)

– Standard laser lines

15 m

– Laser lines with laser re-

ceiver

5–50 m

– Laser points

10 m

Levelling accuracy

B)C)

– Laser lines

±0.3 mm/m

– Laser points

±0.7 mm/m

Self-levelling range

±4°

Levelling time

< 4 s

Operating temperature

–10 °C to +45 °C

Storage temperature

–20 °C to +70 °C

Point and line laser

GCL 2-50 G

Max. altitude

2000 m

Relative air humidity max.

90%

Pollution degree according to
IEC 61010-1

2

D)

Laser class

2

Laser lines

– Laser type

500−540 nm, < 10 mW

– C

6

10

– Divergence

50 × 10 mrad (full angle)

Laser points

– Laser type

500–540 nm, < 1 mW

– C

6

1

– Divergence

0.8 mrad (full angle)

Compatible laser receiver

LR 7

Tripod mount

1/4"

Batteries

4 × 1.5 V LR6 (AA)

Weight according to
EPTA-Procedure 01:2014

0.58 kg

Dimensions (length × width × height)

– Without holder

126 × 63 × 115 mm

– With rotating mount RM 10

145 × 63 × 180 mm

Protection rating

IP 64

A) The working range may be reduced by unfavourable environ-

mental conditions (e.g. direct sunlight).

B) At

20–25

 °C

C) The values stated presuppose normal to favourable environ-

mental conditions (e.g. no vibration, no fog, no smoke, no direct
sunlight). Extreme fluctuations in temperature can cause devi-
ations in accuracy.

D) Only non-conductive deposits occur, whereby occasional tem-

porary conductivity caused by condensation is expected.

The serial number

(10)

 on the type plate is used to clearly identify

your measuring tool.

Assembly

Inserting/Changing the batteries

It is recommended that you use alkaline manganese batter-
ies to operate the measuring tool.
Press the locking mechanism

(7)

 upwards to open the bat-

tery compartment cover

(8)

 and remove the battery com-

partment cover. Insert the batteries.
When inserting the batteries, ensure that the polarity is cor-
rect according to the illustration on the inside of the battery
compartment.
The battery indicator

(2)

 always indicates the current status

of the battery.
If the batteries are running low, the laser lines will gradually
become dimmer.
