30

 | English

1 609 92A 0XL | (29.9.14)

Bosch Power Tools

Technical Data

Noise/Vibration Information

Sound emission values determined according to
EN 61029-2-9.

Typically the A-weighted noise levels of the product are:
Sound pressure level 94 dB(A); Sound power level
104 dB(A). Uncertainty K = 3 dB.

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to EN 61029:
a

h

= 3.0 m/s

2

, K = 1.5 m/s

2

.

The vibration emission level given in this information sheet has
been measured in accordance with a standardised test given in
EN 61029 and may be used to compare one tool with another.
It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained,
the vibration emission may differ. This may significantly in-
crease the exposure level over the total working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working pe-
riod.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.

Declaration of Conformity

We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with all rele-
vant provisions of the directives 2011/65/EU, 2014/30/EU,
2006/42/EC including their amendments and complies with
the following standards: EN 61029-1, EN 61029-2-9.

Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ETM9,
70764 Leinfelden-Echterdingen, GERMANY

Robert Bosch GmbH, Power Tools Division
70764 Leinfelden-Echterdingen, GERMANY
Leinfelden, 19.08.2014

Assembly



Avoid unintentional starting of the machine. During
assembly and for all work on the machine, the power
plug must not be connected to the mains supply.

Delivery Scope

Carefully remove all parts included in the delivery from their
packaging.

Remove all packaging material from the machine and the ac-
cessories provided.

Before starting the operation of the machine for the first time,
check if all parts listed below have been supplied:

– Sliding mitre saw with mounted saw blade
– Locking knob

12

– Dust  bag

1

– Extraction adapter

48

– Open-end spanner

45

– Tool storage

42

 with open-end spanner

45

, hex key

46

,

and hex key

47

– Socket spanner/hex key/cross-head screwdriver

33

– Quick-action clamp

21

Sliding Mitre Saw

GCM 10 SD

Article number 0 601 B22 ...

...  503
...  508
...  532
...  542

...  537

...  541

Rated power input

W

1 800

1 800

1 450

No-load speed

min

-1

5 000

5 000

4 500

Weight according to EPTA-Procedure 01/2003

kg

27

27

27

Protection class

/

II

/

II

/

II

Dimension of suitable saw blades

Saw blade diameter

mm

254

254

254

Blade body thickness

mm

2.0

2.0

2.0

Mounting hole diameter

mm

30

25.4

30

Permissible workpiece dimensions (maximum/minimum) see page 33.

The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.

Starting cycles generate brief voltage drops. Interference with other equipment/machines may occur in case of unfavourable mains system conditions.
Malfunctions are not to be expected for system impedances below 0.15 ohm.

Henk Becker
Executive Vice President
Engineering

Helmut Heinzelmann
Head of Product Certification
PT/ETM9
