Product Features

The numbering of the components shown refers to the repre-
sentation of the power tool on the graphic pages.

1

Dust bag

2

Transport handle (front)

3

Clamp for handle

4

Tongue for grade-adjustment of handle

5

Handle

6

Button for releasing locking lever

41

7

Saw blade

8

Retracting blade guard

9

Roller

10

Insert plate

11

Locking bracket

12

Locking knob for various mitre angles

13

Mitre detent lever

14

Bevel lock lever

15

Detents for standard mitre angles

16

Saw table

17

Mounting holes

18

Fence

19

Fence extension

20

Locking screw for fence extension

21

Quick-action clamp

22

Angle indicator (vertical) for rightward bevel angle
range

23

Slide device

24

Cable holder

25

On/Off switch

26

Transport safety-lock

27

Adjusting screw of depth stop

28

Transport handle (rear)

29

Locking screw for slide device

30

Scale for bevel angle

31

Angle indicator (vertical) for leftward bevel angle
range

32

Adjustment knob for 33.9 ° bevel angle

33

Socket spanner (14 mm)/Hex key (4 mm)/Cross-head
screwdriver

34

Lock screw of the material stop

35

Material stop

36

Saw-table extension

37

Tensioning lever for saw-table extension

38

Scale for mitre angle

39

Rotary knob for adjustment of the bevel angle range

40

Spindle lock

41

Locking lever

42

Tool storage

43

Fastening screws for tool storage

44

Fastening nut for tool storage

45

Open-end spanner (17 mm; 10 mm)

46

Hex key (3 mm)

47

Hex key(1.5 mm)

48

Extraction adapter

49

Chip ejector

50/51

Cross-head screw (attachment of retracting
blade guard)

52

Hexagon bolt for saw-blade attachment

53

Washer

54

Clamping flange

55

Interior clamping flange

56

Holes for quick-action clamp

57

Clamping lever of the quick-action clamp

58

Threaded rod

59

Screws for insert plate

60

Clamping screw of the material stop

61

Button for rapid-setting of the adjusting screw

27

62

Depth stop

63

–

66

Set screws for 0 ° basic setting (bevel angle)

67

Set screw for 45 ° basic setting (leftward bevel angle)

68

Set screw for 45 ° basic setting (rightward bevel angle)

69

Set screw for clamping force of lock lever

14

70

Set screw for clamping force of clamp

3

71

Mitre angle indicator

72

Adjustment screw of the fence extension

73

Hex socket screws (14 mm) of the fence

74

Recessed handles

Accessories shown or described are not part of the standard deliv-
ery scope of the product. A complete overview of accessories can
be found in our accessories program.
