Product Description and
Specifications

Read all safety warnings and all instruc-
tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire
and/or serious injury.

Intended Use

The power tool is intended as a stationary machine for making
straight lengthways and crossways cuts in wood. In this, hori-
zontal mitre angles from – 52 ° to +60 ° as well as vertical bevel
angles from 47 ° (leftward) to 46 ° (rightward) are possible.
The capacity of the power tool is designed for sawing hard-
wood and softwood.

The power tool is not suitable for cutting aluminium or other
non-ferrous metals or alloys.



Keep hands away from the cutting ar-
ea while the machine is running.

Dan-

ger of injury when coming in contact
with the saw blade.



Danger area! Keep hands, fingers or
arms away from this area.

Observe the dimensions of
the saw blade. The hole di-
ameter must match the tool
spindle without play. Do not
use reducers or adapters.

When transporting the machine, hold it only at the locations
indicated.

Danger of crushes or contu-
sions! When transporting,
ensure that your fingers are
positioned around the trans-
port handle.

Indicates the individual steps for adjusting
the handle.

Symbols and their meaning

Indicates the individual
steps for adjusting the bevel
angle.

Left column:
– Bevel angle range

Saw blade is inclined to
the left

Right column:
– Bevel angle range

Saw blade is inclined to
the right

– Bevel angle range

Complete tilting range of
the tool arm

Indicates the position of the
locking lever for locking the
tool arm and for adjusting
the bevel angle.

Do not dispose of power tools into house-
hold waste!

Only for EC countries:

According to the European Guideline
2012/19/EU for Waste Electrical and
Electronic Equipment and its implementa-
tion into national right, power tools that
are no longer usable must be collected
separately and disposed of in an environ-
mentally correct manner.

Symbols and their meaning

45°– 0

0 – 45°

45°+
