English

 25

Maintenance schedule

Time

Activity

Assembly affected

Remedy

of whom

daily

Check safety installa-
tions

Emergency-stop button on operating
point for manual mode, wash card/
code reader, all other emergency-stop
buttons in the plant, safety switches in
the small halls.

Start wash programme, activate emergen-
cy-stop buttons or safety switches. The
plant must stop, then press the control sup-
ply voltage/normal position button on the
operating point for manual mode.

Operator

Check notes for self-op-
eration customers (only
with self-operation
plants).

Signs with operation instructions and
proper use according to the stipula-
tions to be placed at the wash place.

Check signs for completeness and legibili-
ty. Replace damaged signs.

Operator

Check filling level of the
detergent.

The detergent container is located in
the column on the right when facing
the direction of travel

If necessary, fill up.

Operator

Check spray jets for
blockage

Jets in the upper section, jet pipes on
the columns and the underfloor wash
plant (option), also high-pressure jets
(option)

Make visible inspection (judge spray pic-
ture), if necessary, clean. Warning! Do not
mix up jets! Screw off jets individually,
clean with compressed air, screw on
again.

Operator

Clean light barriers.

All light barriers (diagrams 2 und 9)

Applying gentle pressure, wipe light barri-
ers with a detergent-free soft, damp cloth.

Operator

Visual inspection

All limit switches (see diagrams 3 to 6) Check for mechanical damage and stable

seating.

Operator

Check brush rollers for
foreign bodies

Side-brushes, roof brush, wheel
brushes

Make visible inspection, remove possible
foreign bodies that are present, clean
soiled brushes with high-pressure cleaner.

Operator

Check water supply

Rinse and spray circulation

Shut off water in manual operation and
check whether enough water is present in
the vehicle wash. Too little or no water may
cause damage to the vehicle being
washed.

Operator

Function test

Positioning ramp

Interrupt light barriers "position 1“ and "po-
sition 2“ (see Fig. 2). The positioning ramp
must indicate corresponding signal.

Operator

weekly or
after 500
washes

Check condition of the
washing brushes.

Roof brush roll and side brush rolls

Check brush shaft for straightness, check
brush segments on firm seating, check
brush for wear (minimum bristle length:
new state minus 50 mm) if necessary, re-
place.

Operator

Wheel washing brushes

Replace brushes after approx. 10000
washing processes. For this: loosen 3
screws within the bristle ring, remove
wheel washing brush, attach new wheel
washing brush and fasten it with the 3
screws.

Opera-
tor/Cus-
tomer
Service

Check hoses and piping
for absence of leakness.

Hoses of the supply line and in the
portal

Visual inspection

Opera-
tor/Cus-
tomer
Service

after 1000
washes

Visual inspection

Running rollers of the side-brushes’
wagon (Diag. 7)

Check play by moving the side-brushes.
Inform Customer Service when there is too
much play between roller truck and guide:

Operator

Reset

Screws for guide rails (roof brush, roof
drier)

Check using a hexagon socket wrench that
screws are firmly screwed in, tighten if nec-
essary (apply approx. 25 Nm tightening
torque)

Opera-
tor/Cus-
tomer
Service
