Controller for units

FWECSA

INPUT STATUS

 (READ-ONLY DIGITAL)

DESCRIPTION

1

unit ON/OFF

2

SUMMER/WINTER

3

ECONOMY on

4

ANTI-FREEZE on

5

ALARM installed

6

Room temperature probe alarm

7

Water temperature probe alarm

8

Hot water temperature probe alarm
(only with 4-pipe units)

9

Room humidity probe alarm

10

Speed number (3/4)

11

Pipe number (2/4)

12

Type of ventilation (STEP/MODULATING)

13

Adjustment probe (DISPLAY/BOARD)

14

Installed electrical heaters

15

Installed humidity probe

16

Digital output 1 status (01)

17

Digital output 2 status (02)

18

Digital output 3 status (03)

19

Digital output 4 status (04)

20

Digital output 5 status (05)

21

Digital output 6 status (06)

22

Digital output 7 status (07)

23

Water probe presence

24

Hot water probe presence (hydronic unit with 4 pipes)

25

Dehumidification active

26

Valve open

27

Hydronic unit switched off from remote contact

28

Ventilation control (manual/automatic)

29

Heater active

30

Valve presence

31

Enable ECONOMY from contact

HOLDING REGISTER

(READING/WRITING WHOLES/ANALOGUES)

DESCRIPTION

1

Summer temperature SET (cooling)

2

Summer temperature SET minimum limit

3

Summer temperature SET maximum limit

4

Winter temperature SET (heating)

5

Winter temperature SET minimum limit

6

Winter temperature SET maximum limit

7

Single temperature SET
(if SUM/WIN on water/air temp.)

8

Humidity SET

9

Minimum humidity SET limit

10

Maximum humidity SET limit

11

Step ventilation speeds:
0 = extra-low speed
1 = low speed
2 = medium speed
3 = maximum speed
4 = AUTO speed

12

Modulating ventilation speed

INPUT REGISTER

(READ-ONLY WHOLES/ANALOGUES)

DESCRIPTION

1

Room temperature

2

Room humidity

3

Water temperature

4

Hot water temperature (only with 4-pipe units)

5

Step ventilation status:
0 = no ventilation
1 = extra-low speed
2 = low speed
3 = medium speed
4 = maximum speed

6

Modulating ventilation % value

7

% value of analogue output 1

8

% value of analogue output 2

9

% value of analogue output 3

10

Temperature SET on

11

Summer temperature SET

12

Winter temperature SET

13

Single temperature SET
(if SUM/WIN on water/air temp.)

14

Humidity SET on

15

Type of valve (NOT INCLUDED/ON-OFF/MODULATING)
