 English |

13

Bosch Power Tools

1 609 92A 0KJ | (6.5.14)



Do not operate the measuring tool in explosive environ-
ments, such as in the presence of flammable liquids,
gases or dusts.

Sparks can be created in the measuring

tool which may ignite the dust or fumes.

Keep the measuring tool away from cardiac
pacemakers.

The magnet inside the measur-

ing tool generates a field that can impair the
function of cardiac pacemakers.



Keep the measuring tool away from magnetic data me-
dia and magnetically-sensitive equipment.

The effect of

the magnet can lead to irreversible data loss.

Product Description and Specifica-
tions

Please unfold the fold-out page with the representation of the
measuring tool and leave it unfolded while reading the operat-
ing instructions.

Intended Use

The measuring tool is intended for determining and checking
horizontal and vertical lines.

Technical Data

Product Features

The numbering of the product features shown refers to the il-
lustration of the measuring tool on the graphic page.

1

Exit opening for laser beam

2

Pulse-function indicator

3

Pulse-function button

4

Operating mode button

5

Battery indicator

6

Tripod mount 1/4"

7

On/Off switch

8

Battery lid

9

Serial number

10

Laser warning label

11

Latch of battery lid

12

Alignment plate *

13

0 ° alignment aid on the alignment plate

14

90 ° alignment aid on the alignment plate

15

45 ° alignment aid on the alignment plate

16

Pin on the alignment plate

17

Protective pouch *

18

Case *

19

Laser viewing glasses *

20

Measuring plate with stand *

21

Laser receiver *

* The accessories illustrated or described are not included as
standard delivery.

Cross-line Laser

GLL2-50 Professional

Article number

3601K631..

Working range

– Standard
– With pulse function
– With  laser  receiver

20 m
15 m
50 m

Levelling Accuracy

± 0.3 mm/m

Self-levelling range, typically

± 4 °

Levelling duration, typically

< 4 s

Operating temperature

– 10 ° C...+ 50 ° C

Storage temperature

– 20 ° C...+ 70 ° C

Relative air humidity, max.

90 %

Laser class

2

Laser type

635 nm,< 1 mW

C

6

1

Shortest pulse duration

1/1 600 s

Tripod mount

1/4"

Batteries

3 x 1.5 V LR6 (AA)

Operating time, approx.

12 h

Automatic switch-off after approx.

30 min

Weight according to EPTA-Procedure 01/2003

0.45 kg

Dimensions

118 x 57 x 89 mm

Degree of protection

IP 54 (dust and splash water protected)

The measuring tool can be clearly identified with the serial number

9

 on the type plate.
