Electromagnetic Immunity (IEC60601-1-2)

Immunity test

IEC60601-1-2

test level

Compliance

level

Electromagnetic envi

-

ronment - guidance

Electrostatic

discharge (ESD)

IEC 61000- 4-2

±6 kV contact

±8 kV air

±6 kV contact

±8 kV air

Floors should be wood,

concrete or ceramic tile.

If floors are covered

with synthetic material,

the relative humidity

should be at least 30 %.

Electric fast

transient/burst

IEC 61000- 4- 4

±2 kV for

power supply

lines

±1 kV for

input/output lines

±2 kV for

power supply

lines

±1 kV for

input/output lines

Mains power quality

should be that of a

typical commercial or

hospital environment.

Surge

IEC 61000- 4-5

±1 kV

differential mode

±2 kV

common mode

±1 kV

differential mode

±2 kV

common mode

Mains power quality

should be that of a

typical commercial or

hospital environment.

Voltage dips, short

interruptions and

voltage variations

on power supply

input lines

IEC 61000- 4-11

<5 % U

T

for 0.5 cycle

<5 % U

T

for 0.5 cycle

Mains power quality

should be that of a

typical commercial or

hospital environment.

If the user of the

HBP-1100 requires

continued operation

during power mains

interruptions, it is

recommended that the

HBP-1100 be powered

from an uninterruptible

power supply or

batteries.

40 % U

T

for 5 cycles

40 % U

T

for 5 cycles

70 % U

T

for 25 cycles

70 % U

T

for 25 cycles

U

T

: Rated voltage

of test unit

<5 % U

T

for 5 sec.

<5 % U

T

for 5 sec.

Power frequency

(50/ 60 Hz)

magnetic field

IEC 61000- 4-8

3 A/m (r.m.s)

3 A/m (r.m.s)

Power frequency

magnetic fields

should be at levels

characteristic of a

typical location in a

typical commercial or

hospital environment.

Note: U

T

 is the a.c. mains voltage prior to application of the test level.
