Laser protection cap

(16)

Retracting blade guard

(17)

Guide roller

(18)

Clamping screw for saw table extension

(19)

Assembly holes

(20)

Saw table

(21)

Insert plate

(22)

Locking clamp

(23)

Locking knob for all mitre angles

(24)

Mitre pre-setting lever

(25)

Tilt protector

(26)

Angle indicator for mitre angles

(27)

Detents for standard mitre angles

(28)

Scale for mitre angles

(29)

Saw table extension

(30)

Recessed handles

(31)

Holes for screw clamp

(32)

SDS bolt

(33)

On/off switch

(34)

On/off switch for laser (cutting line indication)

(35)

Laser warning label

(36)

Chip ejector

(37)

Slide device

(38)

Locking screw for the adjustable fence

(39)

Hex key (6 mm/4 mm)

(40)

Screw clamp

(41)

Depth stop adjusting screw

(42)

Depth stop

(43)

Spindle lock

(44)

Angle indicator for left-hand bevel angle range

(45)

Stop for standard 0° bevel angle

(46)

Chip deflector

(47)

Hex socket screw for mounting the saw blade

(48)

Clamping flange

(49)

Saw blade

(50)

Inner clamping flange

(51)

Threaded rod

(52)

Wing bolt

(53)

Laser beam outlet aperture

(54)

Screws for insert plate

(55)

Length stop

(56)

Locking screw for length stop

(57)

Clamping screw for length stop

(58)

Set screw for laser positioning (right of the saw
blade)

(59)

Hex key (2.5 mm)

(60)

Set screw for laser positioning (left of the saw
blade)

(61)

Screw for laser protection cap

(62)

Fastening screw for laser mounting plate

(63)

Fastening screw for laser housing

(64)

Stop screw for 0° bevel angle

(65)

Stop screw for left-hand bevel angle range

(66)

Stop screw for right-hand bevel angle range

(67)

Set screws for mitre angle scale

(68)

Screw for mitre angle indicator

(69)

Hook-and-loop strap

A)

Not available in all country-specific versions.

Technical Data

Sliding mitre saw

GCM 12 SDE

GCM 12 SDE

GCM 12 SDE

Article number

3 601 M23 1..

3 601 M23 14.

3 601 M23 1B.

3 601 M23 16.

Rated power input

W

1800

1800

1450

No-load speed

min

-1

3300–4300

3300–4300

4000

Starting current limitation

●

●

–

Laser type

nm

650

650

650

mW

< 1

< 1

< 1

Laser class

1

1

1

Divergence of laser line

mrad (full

angle)

1.0

1.0

1.0

Weight according to EPTA-
Procedure 01:2014

kg

28.4

28.4

28.4

Protection class

 / II

 / II

 / II

Dimensions of suitable saw blades

Saw blade diameter

mm

305

305

305
