Assembly



Avoid unintentional starting of the machine. During as-
sembly and for all work on the machine, the power plug
must not be connected to the mains supply.

Delivery Scope

Please also observe the representation of the
delivery scope at the beginning of the operat-
ing instructions.

Before starting the operation of the machine
for the first time, check if all parts listed be-
low have been supplied:

– Table saw with mounted saw blade

26

 and riving knife

25

– Angle  stop

3

– Profile rail

28

– Fastening kit “profile rail”

 40

 (guide plate, knurled nut,

screw, washer)

– Parallel guide

10

– Auxiliary parallel guide

37

– “Auxiliary  parallel  guide” fastening kit

38

(3 fastening

screws, 3 washers, 3 wing nuts)

– Blade guard

6.x

*

* depending on country version:

6.1

/

6.2

– Hex  key

21

– Hex  key

64

– Ring spanner

22

– Push  stick

23

– Insert  plate

24

– Extraction adapter

32

Note:

Check the power tool for possible damage.

Before further use of the machine, check that all protective
devices are fully functional. Any lightly damaged parts must
be carefully checked to ensure flawless operation of the tool.
All parts must be properly mounted and all conditions fulfilled
that ensure faultless operation.
Damaged protective devices and parts must be immediately
replaced by an authorised service centre.

Mounting Individual Components

– Carefully remove all parts included in the delivery from

their packaging.
Remove all packaging material from the machine and the
accessories provided.

– Take care that the packaging material under the motor

block es removed.

The following product features are fastened directly to the
housing:
Push stick

23

, ring spanner

22

, hex key

21

 and

64

, parallel

guide

10

, angle guide

3

, extraction adapter

32

, auxiliary par-

allel guide

37

 with fastening kit

38

, blade guard

6.x

.

– Carefully remove these product features from their stor-

age locations.
Also see figures Y1 – Y6.

Mounting the Insert Plate (see figure A)

– Hook  insert  plate

24

 into the rear insert-plate notches

34

of the tool basin.

– Guide the insert plate down.
– Press on the insert plate until it engages at the front in the

tool basin.

The front side of the insert plate

24

 must be flush with or

somewhat lower than the saw table; the rear side must be
flush with or somewhat above the saw table. (also see “Ad-
justing the Level of the Insert Plate”, page 36)

Mounting the Blade Guard* (see figure B)
* depending on country version

– Turn  crank

19

 clockwise to the stop, so that the saw blade

26

 is in the highest possible position above the saw table.

– Pull the riving knife

25

 upward to the stop.

– Insert the blade guard

6.x

 into the recess in riving knife

25

.

– Tighten the clamping lever

8.1

.

or

Tighten clamping screw

8.2

 with hex key

21

.

– Adjust the blade guard according to the workpiece height.

When sawing, the blade guard must always face lightly
against the workpiece.

Note:

Clamping lever

8.1

 is indexed (adjustable), allowing it

to be set to an ergonomically favourable or space-saving posi-
tion.
With the clamping lever tightened, pull its lever away from the
blade guard, turn it to the desired position and allow it to en-
gage again.

Mounting the Parallel Guide (see figure C)

The parallel guide

10

 can be positioned either left or right

from the saw blade.

– Loosen clamping handle

35

 of parallel guide

10

.

This releases V-guide

36

.

– Firstly, mount the parallel guide via the V-guide in guide

groove

11

 of the saw table. Now, position the parallel

guide into the front guide groove

2

 of the saw table.

The parallel guide can now be moved to any position.

– To lock the parallel guide, press the clamping handle

35

down.

Mounting the Auxiliary Parallel Guide (see figure D)
When sawing narrow workpieces and bevel angles,

 the

auxiliary parallel guide

37

 must be mounted to parallel guide

10

.

The auxiliary parallel guide can be mounted left or right from
parallel guide

10

, as required.

For assembly, use the “auxiliary parallel guide” fastening kit

38

.  (3 fastening screws, 3 washers, 3 wing nuts)

– Insert the fastening screws  through the lateral holes in the

parallel guide

10

.

The heads of the screws serve as a guide for the auxiliary
parallel guide.

– Move the auxiliary parallel guide

37

 over the heads of the

fastening screws.

– Mount the washers  to the fastening screws and tighten

them with the wing nuts.
