When bucking on a slope, always stand on the
uphill side of the log. When “cutting through”,
release the cutting pressure near the end of
the cut without relaxing your grip on the chain
saw handles in order to maintain complete
control. Don’t let the chain contact the
ground. After completing the cut, wait for the
saw chain to stop before you move the chain
saw. Always stop the chain saw motor before
moving from tree to tree.

Battery Charge-control Indication
(see figure B)

The battery

17

 is equipped with a charge-con-

trol indicator

20

 which indicates its charge

condition. The charge-control indicator

20

consists of 3 green LEDs.
Press the button

19

 to actuate the charge-

control indicator

20

. After approx. 5 seconds,

the charge-control indicator goes out auto-
matically.
The charge condition can also be checked
when the battery is removed.
When no LED lights up after actuating the but-
ton

19

, the battery is defective and must be

replaced.
For safety reasons, the charge condition of
the battery can only be checked when the
power tool is at a standstill.

During the charging procedure, the three
green LEDs light up one after the other and
briefly go out. The battery is fully charged
when the three green LEDs light up continu-
ously. The three LEDs go out again approx.
5 minutes after the battery has been fully
charged.

Temperature Control Indicator

The red LED of the temperature control indi-
cator

21

 signals that the battery or the elec-

tronics of the power tool (when the battery is
inserted) are not within the optimum temper-
ature range. In this case, the power tool will
not operate at full capacity.

Temperature Control of the Battery

The red LED

21

 flashes when pushing button

19

 or pressing the On/Off switch

3

 (when the

battery is inserted): The battery is not wihin
the temperature range for operation of

– 10 ° C  to  + 60 ° C.

The battery switches off at a temperature
above 70 ° C until the optimum temperature
range is reached again.

Temperature control of the power tool elec-
tronics

The red LED

21

 lights up continuously when

pressing the On/Off switch

3

: The tempera-

ture of the machine’s electronics is below
5 ° C  or  above  75 ° C.
At a temperature above 90 ° C , the electron-
ics of the power tool switch off until the tem-
perature is within the allowable temperature
range again.

Troubleshooting

The following chart lists problem symptoms, possible causes and corrective action, if your pow-
er tool does not operate properly. If these do not identify and correct the problem, contact your
service agent.

f

Warning: Switch off and remove the battery prior to any troubleshooting.

LED Indicators

Battery Capacity

Continuous lighting of 3
green LEDs

≥

2/3

Continuous lighting of 2
green LEDs

≥

1/3

Continuous lighting of 1
green LED

≤

1/3

Flashing of 1 green LED Reserve

Problem

Possible Cause

Corrective Action

Chain saw fails
to operate

Kickback brake is activated (a warn-
ing sound (“beep”) can be heard)

Pull activation lever for kickback
brake (hand guard)

6

 back in posi-

tion

n

Battery discharged

Recharge battery; also see “Battery
Charging”

Battery not fully connected

Ensure both locking levels are en-
gaged

Motor protector has activated

Allow motor to cool

Battery too hot/cold

Allow to cool/warm

Saw chain will
not move

Battery discharged

Recharge battery; also see “Battery
Charging”

Power tool defective

Contact Service Agent

Chain saw oper-
ates intermit-
tently

External or internal wiring defect

Contact your Bosch Service Centre

On/Off switch

3

 defective

Contact your Bosch Service Centre

Saw chain dry

No oil in reservoir

Refill oil

Vent in oil filler cap

4

 clogged

Clean oil filler cap

4

Oil passage clogged

Clean oil passage

Brake does not
stop saw chain

Kickback brake defective

Contact your Bosch Service Centre
