Battery Charging (see figure B)

f

Do not use other battery chargers.

The

supplied battery charger is designed for
the Lithium-Ion battery in your machine.

f

Observe the mains voltage!

The voltage of

the power supply must correspond with
the data given on the nameplate of the bat-
tery charger. Battery chargers marked with
230 V can also be operated with 220 V.

The battery is equipped with temperature
monitoring that allows charging only in the
temperature range between 0  ° C and 45  ° C.
In this manner, a high battery service life is
achieved.

Note:

The battery is supplied partially

charged. To ensure full capacity of the bat-
tery, completely charge the battery in the bat-
tery charger before using your power tool for
the first time.
The lithium-ion battery can be charged at any
time without reducing its service life. Inter-
rupting the charging procedure does not dam-
age the battery.
The “Electronic Cell Protection (ECP)” pro-
tects the lithium ion battery against deep dis-
charging. When the battery is run down or dis-
charged, the chain saw is shut off by means of
a protective circuit: The saw chain no longer
moves.

Do not continue to press the
On/Off switch after the ma-

chine has been automatically switched off.

The battery can be damaged.

Charging Procedure

The charging procedure starts as soon as the
mains plug of the battery charger is plugged
into the socket outlet and the battery

17

 is in-

serted into the charging compartment

22

.

Due to the intelligent charging method, the
charging condition of the battery is automati-
cally detected and the battery is charged with
the optimum charging current, depending on
battery temperature and voltage.
This gives longer life to the battery and always
leaves it fully charged when kept in the charg-
er for storage.

Meaning of the Indication Elements

Control of the charging procedure is indicated
via the charge control LEDs

24

 and

25

:

Rapid-charging Procedure

The rapid-charging procedure is indicated by

flashing

 of the

green charge control LED

25

.

Indication element of the battery: During the
charging procedure, the three green LEDs
light up one after the other and briefly go out.
The battery is fully charged when the three
green LEDs light up continuously. The three
LEDs go out again approx. 5 minutes after the
battery has been fully charged.

Note:

The rapid-charging procedure is only

possible when the battery temperature is
within the allowable charging temperature
range, see section “Technical Data”.

Battery Charged

Continuous lighting

 of the

green charge

control LED

25

 signals that the battery is fully

charged.
Additionally, a signal tone sounds for approx.
2 seconds, which acoustically indicates that
the battery is fully charged.
Afterwards, the battery can be removed for
immediate use.
With no battery inserted,

continuous lighting

of the

green charge control LED

25

 indicates

that the mains plug is plugged into the socket
and that the battery charger is ready for oper-
ation.

Battery Temperature below 0 ° C and above
45 ° C

Continuous lighting

 of the

red LED

24

 indi-

cates that the battery temperature is not with-
in the rapid-charging temperature range of
0 ° C – 45 ° C. As soon as the allowable tem-
perature range is reached, the battery charger
automatically switches to rapid charging.
When the battery is not within the allowable
temperature range, the red battery LED lights
up when inserting the battery into the battery
charger.

No charging procedure possible

If a different malfunction of the charging pro-
cedure is present, this will be indicated
through

flashing

 of the

red charge control

LED

24

.

The charging procedure cannot be started
and the battery cannot be charged (see “Trou-
bleshooting”).

Charging Advice

With continuous or several repetitive charging
cycles without interruption, the charger can
warm up. This is not meaningful and does not
indicate a technical defect of the battery
charger.
