 English |

23

Bosch Power Tools

F 016 L70 758 | (22.11.10)

Functional Description

Read all safety warnings and all
instructions.

Failure to follow the

warnings and instructions may
result in electric shock, fire
and/or serious injury.

Intended Use

The power tool is intended for sawing wood
such as wooden beams, planks, branches,
tree trunks, etc., and for sawing of trees. Cuts
can be sawed with or across the grain.
This power tool is not suitable for sawing min-
eral materials.

Delivery Scope

Carefully remove the power tool from its
packaging and check if the following parts are
complete:
– Chain  saw
– Cover
– Chain
– Chain  bar
– Chain guard
– Oil  Sachet
– Operating instructions

Battery and charger are included in certain ex-
ecutions.
When parts are missing or damaged, please
contact your dealer.

Product Features

The numbering of the product features refers
to the illustration of the machine on the
graphics page.

1

Rear handle

2

Lock-off button for On/Off switch

3

On/Off switch

4

Oil filler cap

5

Front handle

6

Activation lever for kickback brake (hand
guard)

7

Oil level gauge

8

Gripping teeth

9

Chain guard

10

Chain bar

11

Saw chain

12

Locking knob

13

Cover

14

Ventilation slots –  outlet

15

Chain tensioning knob

16

Serial number

17

Battery

18

Battery unlocking button

19

Button for charge-control indicator

20

Battery charge-control indicator

21

Temperature control indicator

22

Charging compartment

23

Battery charger

24

Red LED indicator on the battery charger

25

Green LED indicator on the battery charger

26

Power plug **

27

Symbol for rotation and cutting direction

28

Drive sprocket

29

Fastening bolt

30

Chain tensioning peg

31

Oil outlet

32

Guide fin for chain bar

33

Chain catch bolt

34

Ventilation slots –  inlet

** country specific
Accessories shown or described are not part of the
standard delivery scope of the product. A complete
overview of accessories can be found in our acces-
sories program.

Technical Data

Cordless chain saw

AKE 30 LI

Article number

3 600 H37 1..

Chain speed (no-load)

m/s

8

Chain bar length

cm

30

Toolless chain tensioning (SDS)

z

Kickback brake

z

Chain type

3/8" – 90

Drive link thickness

mm

1.1 (0.034" )

Amount of drive links

45

Oil reservoir capacity

ml

120

Automatic chain oiler

z

Metal gripping teeth

z

Weight according to EPTA-Procedure 01/2003

kg

5.2

Serial number

See serial number

16

 (type plate) on the

power tool

Please observe the article number on the type plate of your machine. The trade names of the individual ma-
chines may vary.
