 English |

27

Bosch Power Tools

1 609 92A 0XH | (12.12.14)

Floor Strips/Mouldings

The following table contains instructions for sawing floor strips/mouldings.

Ceiling Strips/Mouldings (According to US Standard)

Checking and Adjusting the Basic Adjustment



Before any work on the machine itself, pull the mains
plug.

To ensure precise cuts, the basic adjustment of the machine
must be checked and adjusted as necessary after intensive use.

A certain level of experience and appropriate specialty tools
are required for this.

A Bosch after-sales service station will handle this mainte-
nance task quickly and reliably.

Settings

Placed
against the
fence

Lying flat on
the saw table

Bevel angle

0 °

45 °

Floor strip/moulding

Left side

Right side

Left side

Right side

Inner corner

Horizontal mitre angle

45 ° left

45 ° right

0 °

0 °

Positioning of
workpiece

Bottom edge on

saw table

Bottom edge on

saw table

Upper edge against

the fence

Bottom edge

against the fence

The finished work-
piece is located ...

... to the left of the

cut

... to the right of the

cut

... to the left of the

cut

... to the left of the

cut

Outer corner

Horizontal mitre angle

45 ° right

45 °  left

0 °

0 °

Positioning of
workpiece

Bottom edge on

saw table

Bottom edge on

saw table

Bottom edge

against the fence

Upper edge against

the fence

The finished work-
piece is located ...

... to the right of the

cut

... to the left of the

cut

... to the right of the

cut

... to the right of the

cut

When the ceiling strips/mouldings are to be sawn lying flat on the saw table, the standard mitre angles of
31.6 ° (horizontal) and 33.9 ° (vertical) must be set.
The following table contains instructions for sawing ceiling strips/mouldings.

Settings

Placed
against the
fence

Lying flat on
the saw table

Bevel angle

0 °

33,9 °

Ceiling strip/moulding

Left side

Right side

Left side

Right side

Inner corner

Horizontal mitre angle

45 ° right

45 ° left

31.6 ° right

31.6 ° left

Positioning of
workpiece

Bottom edge

against the fence

Bottom edge

against the fence

Upper edge against

the fence

Bottom edge

against the fence

The finished work-
piece is located ...

... to the right of the

cut

... to the left of the

cut

... to the left of the

cut

... to the left of the

cut

Outer corner

Horizontal mitre angle

45 ° left

45 ° right

31.6 ° left

31.6 ° right

Positioning of
workpiece

Bottom edge

against the fence

Bottom edge

against the fence

Bottom edge

against the fence

Upper edge against

the fence

The finished work-
piece is located ...

... to the right of the

cut

... to the left of the

cut

... to the right of the

cut

... to the right of the

cut

52°

38°

52°
