Working Advice

General Sawing Instructions



For all cuts, it must first be ensured that the saw blade
at no time can come in contact with the fence, screw
clamps or other machine parts. Remove any mounted
auxiliary stops or adjust them accordingly.

Protect the saw blade against impact and shock. Do not sub-
ject the saw blade to lateral pressure.

Do not saw warped/bent workpieces. The workpiece must al-
ways have a straight edge to face against the fence.

Long workpieces must be underlaid or supported at their free
end.

Position of the Operator (see figure M)



Do not stand in a line with the saw blade in front of the
machine. Always stand aside of the saw blade.

This pro-

tects your body against possible kickback.

– Keep hands, fingers and arms away from the rotating saw

blade.

– Do not cross your arms when operating the tool arm.

Permissible Workpiece Dimensions
Maximum

 workpiece sizes:

Minimum

 workpiece sizes (= all workpieces that can be

clamped left or right from the saw blade with the supplied
material clamp

17

): 170 x 45 mm (length x width)

Cutting depth, max.

(0 °/0 °): 89 mm

Replacing Insert Plates (see figure L)

The red insert plates

7

 can become worn after prolonged use

of the machine.

Replace defective insert plates.

– Bring the power tool into the working position.
– Unscrew  the  screws

42

 using the provided cross-head

screwdriver and remove the old insert plates.

– Insert the new right-hand insert plate.
– Screw the insert plate as far as possible to the right with

the screws

42

 so that the saw blade does not come into

contact with the insert plate over the complete length of
the possible slide motion.

– Repeat the work steps in the same manner for the left-hand

insert plate.

Sawing

Cutting Off

– Firmly clamp the workpiece as appropriate for its dimen-

sions.

– Adjust the requested mitre and/or bevel angle.
– Switch on the machine.
– Press lever

1

 and slowly guide the tool arm downward by

handle

2

.

– Saw through the workpiece applying uniform feed.
– Switch off the machine and wait until the saw blade has

come to a complete stop.

– Guide the tool arm slowly upward.

Special Workpieces

When sawing curved or round workpieces, these must be es-
pecially secured against slipping. At the cutting line, no gap
may exist between workpiece, fence and saw table.

Provide for special fixtures, if required.

Sawing Profile Strips/Mouldings (Floor and Ceil-
ing Strips)

Profile strips/mouldings can be sawn in two different ways:

– Placed against the fence
– Lying flat on the saw table.

Always make trial cuts with the mitre angle setting first on
scrap wood.

Mitre/Bevel Angle

Height x Width [mm]

Horizontal

Vertical

at max.

height

at max. width

0 °

0 °

89 x 89

60 x 130

45 °

0 °

89 x 59

57 x 89

0 °

45 °

58 x 85

38 x 120

45 °

45 °

38 x 76

38 x 76
