The Advanced MCACC menu

10

92

En

3

Select each channel in turn and adjust the

distance as necessary.

Use

/

 to adjust the delay of the speaker

you selected to match the reference speaker.
The delay is measured in terms of speaker
distance from

0.01m

 to

9.00m

.

Listen to the reference speaker and use it to
measure the target channel. From the listening
position, face the two speakers with your arms

outstretched pointing at each speaker. Try to

make the two tones sound as if they are

arriving simultaneously at a position slightly in

front of you and between your arm span.

1

When it sounds like the delay settings are

matched up, press



 to confirm and continue

to the next channel.

• For comparison purposes, the reference

speaker will change depending on which

speaker you select.

• If you want to go back and adjust a

channel, simply use

/

 to select it.

4

When you’re finished, press RETURN.

You will return to the

Manual MCACC

 setup

menu.

Standing Wave

• Default  setting:

ON

2

/

ATT 0.0dB

 (all filters)

Acoustic standing waves occur when, under

certain conditions, sound waves from your

speaker system resonate mutually with sound

waves reflected off the walls in your listening

area. This can have a negative effect on the

overall sound, especially at certain lower

frequencies. Depending on speaker placement,

your listening position, and ultimately the

shape of your room, it results in an overly

resonant (‘boomy’) sound. The Standing Wave

Control uses filters to reduce the effect of overly

resonant sounds in your listening area. During

playback of a source, you can customize the

filters used for Standing Wave Control for each

of your MCACC presets.

3

1

Select  ‘Standing Wave’ from the Manual

MCACC setup menu.

2

Adjust the parameters for the Standing

Wave Control.

•

Filter Channel

 – Select the channel to

which you will apply the filter(s):

MAIN

 (all

except center channel and subwoofer),

Center

 or

SW

(subwoofer).

•

TRIM

(only available when the filter channel

above is

SW

)

 – Adjust the subwoofer

channel level (to compensate for the
difference in output post-filter).

Note

1 • If you can’t seem to achieve this by adjusting the distance setting, you may need to change the angle of your

speakers very slightly.

• For better audibility, the subwoofer emits a continuous test tone (oscillating pulses are heard from your other

speakers). Note that it may be difficult to compare this tone with the other speakers in your setup (depending on the

low frequency response of the reference speaker).

2 You can switch on or off the Standing Wave and Acoustic Calibration EQ feature in the

AUDIO PARAMETER

 menu.

See

Setting the Audio options

 on page 68 for more on this.

3 • Since they will be overwritten, you may want to save the standing wave settings made with the Auto MCACC Setup

to another MCACC preset.

• Standing Wave control filter settings cannot be changed during playback of sources using the HDMI connection.

• When

Standing Wave

 is selected for an MCACC preset memory where

STAND.WAVE

 is set to

OFF

 in the

AUDIO

PARAMETER

,

STAND.WAVE

ON

 is automatically selected.
