Pioneer VSX-920 / VSX-1020 / VSX-1025 - Инструкция по эксплуатации - Страница 64

Control with HDMI function

07

64

En

HDMI Setup

You must adjust the settings of this receiver as
well as the connected

Control

 with HDMI-

compatible components in order to make use
of the

Control

 with HDMI function. For more

information see the operating instructions for

each component.

1

Press ,

then

press

Home Menu.

2

Select ‘System Setup’, then press ENTER.

3

Select ‘Other Setup’, then press ENTER.

4

Select ‘HDMI Setup’, then press ENTER.

5

Select the ‘Control’ setting you want.

Choose whether to set this unit’s

Control

 with

HDMI function

ON

 or

OFF

. You will need to set

it to

ON

 to use the

Control

 with HDMI

function.
When using a component that does not
support the

Control

 with HDMI function, set

this to

OFF

.

•

ON

 – Enables the

Control

 with HDMI

function. When this unit’s power is turned
off and you have a supported source begin

playback while using the

Control

 with

HDMI function, the audio and video
outputs from the HDMI connection are

output from the TV.

•

OFF

– The

Control

 with HDMI is disabled.

Synchronized operations cannot be used.
When this unit’s power is turned off, audio

and video of sources connected via HDMI
are not output.

6

Select the ‘Control Mode’ setting you

want.

Choose whether you want to enable HDMI
for all linked functions or the PQLS function
only. However, Display Power Off will
activate the settings set forth in step 7 below.

•

ALL

 – Enabled for all linked functions.

•

PQLS

– Enabled only for the PQLS

function. When

PQLS

 is selected, link

functions other than the PQLS function

may not work properly. If you wish to use

all link functions, select

ALL

.

7

Select the ‘Display Power Off’ setting

you want.

If the TV’s power is turned off while using the

Control

 with HDMI function, the receiver’s

power is also turned off (all power off
function). This function can be disabled.

•

YES

 – The all power off function is enabled.

The receiver’s power turns off together with
the TV’s power.
This function only works when the input

for a component connected to the
receiver by

Control

 with HDMI is

selected or when watching the TV.

•

NO

– The all power off function is disabled.

The receiver’s power is not affected when
the TV’s power is turned off.

8

When you’re finished, press HOME MENU.

You will return to the

Home Menu

.

RECEIVER

2. Volume  Setup
3. Remote Control Mode Setup
4. Flicker Reduction Setup
5. Pairing Bluetooth Device

1. HDMI  Setup

4e.Other Setup

A/V RECEIVER

E x i t

R e t u r n

4e1.HDMI Setup

A/V RECEIVER

E x i t

F i n i s h

Control

: ON

Control mode

 :

ALL

Display Power Off

:

YES
