Using other functions
08
69
En
English
Français
Deutsch
Nederlands
Italiano
Español
TREBLE
c
Adjusts the amount of treble.
–6 to +6 (dB)
Default:
0
(dB)
S.RTRV
(Sound Retriever)
With the Sound Retriever function, DSP processing is used to
compensate for the loss of audio data upon compression,
improving the sound’s sense of density and modulation.
OFF
d
ON
DNR
(Digital Noise
Reduction)
May improve the quality of sound in a noisy source (for example,
video tape with lots of background noise) when switched on.
OFF
ON
DIALOG E
(Dialog
Enhancement)
Localizes dialog in the center channel to make it stand out from
other background sounds in a TV or movie soundtrack. By moving
from UP1 through UP2 and UP3 up to UP4, you can make the
sound source seem to relocate upwards.
OFF
FLAT
UP1/UP2/UP3/UP4
e
DUAL
(Dual Mono)
Specifies how dual mono encoded Dolby Digital soundtracks
should be played. Dual mono is not widely used, but is sometimes
necessary when two languages need to be sent to separate
channels.
CH1
– Channel 1 is
heard only
CH2
– Channel 2 is
heard only
CH1 CH2
– Both
channels heard from
front speakers
DRC
(Dynamic Range
Control)
Adjusts the level of dynamic range for movie soundtracks
optimized for Dolby Digital, DTS, Dolby Digital Plus, Dolby
TrueHD, DTS-HD and DTS-HD Master Audio (you may need to use
this feature when listening to surround sound at low volumes).
AUTO
f
MAX
MID
OFF
LFE
(LFE Attenuate)
Some audio sources include ultra-low bass tones. Set the LFE
attenuator as necessary to prevent the ultra-low bass tones from
distorting the sound from the speakers.
The LFE is not limited when set to 0 dB, which is the
recommended value. When set to –5 dB, –10 dB, –15 dB or –20
dB, the LFE is limited by the respective degree. When OFF is
selected, no sound is output from the LFE channel.
0dB
/ –5dB/ –10dB/
–15dB/ –20dB
OFF
SACD GAIN
g
Brings out detail in SACDs by maximizing the dynamic range
(during digital processing).
0
(dB)
+6
(dB)
HDMI
h
(HDMI Audio)
Specifies the routing of the HDMI audio signal out of this receiver
(
amp
) or
through
to a TV. When THROUGH is selected, no sound
is output from this receiver.
AMP
THROUGH
A. DELAY
(Auto delay)
This feature automatically corrects the audio-to-video delay
between components connected with an HDMI cable. The audio
delay time is set depending on the operational status of the
display connected with an HDMI cable. The video delay time is
automatically adjusted according to the audio delay time.
i
OFF
ON
Setting
What it does
Option(s)
