Position of the Operator (see figure L)



Do not stand in a line with the saw blade in front of the
machine. Always stand aside of the saw blade.

This pro-

tects your body against possible kickback.

– Keep hands, fingers and arms away from the rotating saw

blade.

– Do not cross your arms when operating the tool arm.

Permissible Workpiece Dimensions
Maximum

 workpiece sizes:

Replacing the Insert Plate (see figure M)

The red insert plate

9

 can become worn after long use of the

power tool.

Replace defective insert plates.

– Bring the power tool into the working position.
– Unscrew  the  screws

46

 using the cross-head screwdriver

22

 provided and remove the old insert plate.

– Screw the insert plate with the screws

46

 as far as possible

to the right, so that the saw blade does not come in contact
with the insert plate throughout the complete possible rip-
ping length.

Sawing

Cutting Off

– Firmly clamp the workpiece as appropriate for its dimen-

sions.

– Adjust the requested mitre and/or bevel angle.
– Set the height of the adjusting screw

30

 so that the work-

piece can be sawn through completely (see also “Adjusting
the Depth Stop”, page 26).

– Switch on the machine.
– Press lever

2

 and slowly guide the tool arm downward by

handle

3

.

– Saw through the workpiece applying uniform feed.
– Switch off the machine and wait until the saw blade has

come to a complete stop.

– Guide the tool arm slowly upward.

Adjusting the Depth Stop (Sawing Grooves) (see figure N)

The adjusting screw

30

 of the depth stop has to be turned

clockwise if you want to saw a groove.

– Tilt the tool arm by the handle

3

 to the position at which the

requested groove depth is reached.

– Turn the adjusting screw

30

 clockwise until the end of the

screw touches the housing stop.

– Guide the tool arm slowly upward.

Special Workpieces

When sawing curved or round workpieces, these must be es-
pecially secured against slipping. At the cutting line, no gap
may exist between workpiece, fence and saw table.

Provide for special fixtures, if required.

Sawing Profile Strips

Profile strips/mouldings can be sawn in two different ways:

– Placed against the fence
– Lying flat on the saw table.

Always make trial cuts with the mitre angle setting first on
scrap wood.

The following table contains instructions for sawing floor
strips/mouldings.

Mitre/Bevel Angle

Height x Width [mm]

Horizontal

Vertical at max. height

at max. width

0 °

0 °

89 x 89

62 x 130

45 °

0 °

86 x 67

65 x 91

0 °

45 °

44 x 95

32 x 130

45 °

45 °

44 x 67

32 x 91

Settings

Placed
against the
fence

Lying flat on
the saw table

Bevel angle

0 °

45 °

Floor strip/moulding

Left side

Right side

Left side

Right side

Inner corner

Horizontal mitre angle

45 ° left

45 ° right

0 °

0 °

Positioning of work-
piece

Bottom edge on

saw table

Bottom edge on

saw table

Upper edge against

the fence

Bottom edge

against the fence

The finished work-
piece is located ...

... to the left of the

cut

... to the right of the

cut

... to the left of the

cut

... to the left of the

cut

Outer corner

Horizontal mitre angle

45 ° right

45 °  left

0 °

0 °

Positioning of work-
piece

Bottom edge on

saw table

Bottom edge on

saw table

Bottom edge

against the fence

Upper edge against

the fence

The finished work-
piece is located ...

... to the left of the

cut

... to the right of the

cut

... to the right of the

cut

... to the right of the

cut
