Monitoring the System
325
S3300 Smart Managed Pro Switch
EAP Statistics
Use the EAP Statistics screen to display information about EAP packets received on a
specific port.
To display the EAP statistics screen, select
Monitoring
>
Ports
>
EAP Statistics
.
The following table describes the EAP statistics displayed on the screen.
Table 103. EAP statistics
Field
Description
Ports
The interface which is polled for statistics.
Frames Received
The number of valid EAPOL frames received on the port.
Frames Transmitted
The number of EAPOL frames transmitted through the port.
Start Frames Received
The number of EAPOL Start frames received on the port.
Logoff Frames Received
The number of EAPOL Log off frames that have been received on the port.
Last Frame Version
The protocol version number attached to the most recently received EAPOL
frame.
Last Frame Source
The source MAC Address attached to the most recently received EAPOL
frame.
Invalid Frames Received
The number of unrecognized EAPOL frames received on this port.
Length Error Frames Received
The number of EAPOL frames with an invalid Packet Body Length received on
this port.
Response/ID Frames Received The number of EAP Respond ID frames that have been received on the port.
Response Frames Received
The number of valid EAP Response frames received on the port.
Request/ID Frames
Transmitted
The number of EAP Requested ID frames transmitted through the port.
Request Frames Transmitted
The number of EAP Request frames transmitted through the port.
Use the buttons at the bottom of the screen to perform the following actions:
•
To clear all the EAP counters for all ports on the switch, select the check box in the
row heading and click the
Clear
button. The button resets all statistics for all ports to
default values.
•
To clear the counters for a specific port, select the check box associated with the port
and click the
Clear
button.
Click
Update
to update the page with the latest information on the switch.
