Configuring Routing
214
S3300 Smart Managed Pro Switch
Configure VLAN Routing
You can configure the switch software with some ports supporting VLANs and some
supporting routing. You can also configure the software to allow traffic on a VLAN to be
treated as if the VLAN were a router port.
When a port is enabled for bridging (default) rather than routing, all normal bridge processing
is performed for an inbound packet, which is then associated with a VLAN. Its MAC
Destination Address (MAC DA) and VLAN ID are used to search the MAC address table. If
routing is enabled for the VLAN, and the MAC DA of an inbound unicast packet is that of the
internal bridge-router interface, the packet is routed. An inbound multicast packet is
forwarded to all ports in the VLAN, plus the internal bridge-router interface, if it was received
on a routed VLAN.
Since a port can be configured to belong to more than one VLAN, VLAN routing might be
enabled for all of the VLANs on the port, or for a subset. VLAN Routing can be used to allow
more than one physical port to reside on the same subnet. It could also be used when a
VLAN spans multiple physical networks, or when additional segmentation or security is
required. This section shows how to configure switch software to support VLAN routing. A
port can be either a VLAN port or a router port, but not both. However, a VLAN port can be
part of a VLAN that is itself a router port.
VLAN Routing Wizard
The VLAN Routing Wizard creates a VLAN routing interface, configure the IP address and
subnet mask for the interface, and add selected ports or LAGs to the VLAN. With this wizard,
you can:
•
Create a VLAN.
•
Add selected ports to the newly created VLAN and remove selected ports from the default
VLAN.
•
Optionally, you can create a LAG, add selected ports to a LAG, then add the LAG to the
newly created VLAN.
•
Enable tagging on selected ports if the port is in another VLAN. Disable tagging if a
selected port does not exist in another VLAN.
•
Exclude ports not selected from the VLAN.
•
Enable routing on the VLAN using the IP address and subnet mask entered.
To configure VLAN routing using the VLAN routing wizard:
1.
Click
Routing
>
VLAN
>
VLAN Routing Wizard
.
2.
In the VLAN ID field, specify the VLAN Identifier (VID) associated with this VLAN. The VID is
1 to 4093 characters in length.
3.
In the IP Address field, define the IP address of the VLAN interface.
4.
In the Network Mask field, define the subnet mask of the VLAN interface.
5.
Click to view the ports or LAGs.
