Monitoring the System
323
S3300 Smart Managed Pro Switch
Total Packets Transmitted
(Octets)
The total number of octets of data (including those in bad packets) transmitted on
the network (excluding framing bits but including FCS octets). This object can be
used as a reasonable estimate of Ethernet utilization. If greater precision is
desired, the etherStatsPkts and etherStatsOctets objects should be sampled
before and after a common interval.
Packets Transmitted 64
Octets
The total number of packets (including bad packets) transmitted that were 64
octets in length (excluding framing bits but including FCS octets).
Packets Transmitted
65-127 Octets
The total number of packets (including bad packets) transmitted that were
between 65 and 127 octets in length inclusive (excluding framing bits but including
FCS octets).
Packets Transmitted
128-255 Octets
The total number of packets (including bad packets) transmitted that were
between 128 and 255 octets in length inclusive (excluding framing bits but
including FCS octets).
Packets Transmitted
256-511 Octets
The total number of packets (including bad packets) transmitted that were
between 256 and 511 octets in length inclusive (excluding framing bits but
including FCS octets).
Packets Transmitted
512-1023 Octets
The total number of packets (including bad packets) transmitted that were
between 512 and 1023 octets in length inclusive (excluding framing bits but
including FCS octets).
Packets Transmitted
1024-1518 Octets
The total number of packets (including bad packets) transmitted that were
between 1024 and 1518 octets in length inclusive (excluding framing bits but
including FCS octets).
Packets Transmitted > 1518
Octets
The total number of packets transmitted that were longer than 1518 octets
(excluding framing bits, but including FCS octets) and were otherwise well formed.
This counter has a max increment rate of 815 counts per sec at 10 Mb/s.
Maximum Frame Size
The maximum ethernet frame size the interface supports or is configured,
including ethernet header, CRC, and payload. (1518 to 9216). The default
maximum frame size is 1518.
Total Packets Transmitted
Successfully
The number of frames that have been transmitted by this port to its segment.
Unicast Packets
Transmitted
The total number of packets that higher-level protocols requested be transmitted
to a subnetwork-unicast address, including those that were discarded or not sent.
Multicast Packets
Transmitted
The total number of packets that higher-level protocols requested be transmitted
to a Multicast address, including those that were discarded or not sent.
Broadcast Packets
Transmitted
The total number of packets that higher-level protocols requested be transmitted
to the Broadcast address, including those that were discarded or not sent.
Transmit Packets
Discarded
The number of outbound packets which were chosen to be discarded even though
no errors had been detected to prevent their being deliverable to a higher-layer
protocol. A possible reason for discarding a packet could be to free up buffer
space.
Total Transmit Errors
The sum of Single, Multiple, and Excessive Collisions.
Table 102. Detailed Interface Statistics (continued)
Field
Description
