Configuring Switching
199
S3300 Smart Managed Pro Switch
MSRP Reservation Parameters
Use the MSRP Reservation Parameters screen to view information about the talker, listener,
and intermediate device status for the devices involved in each MSRP stream flowing
through the switch.
To view the MSRP Reservation Parameters screen, select
Switching
>
MRP
>
Advanced
>
MSRP Reservation Parameters
.
The following table describes status fields on the MSRP Reservation Parameters screen.
Table 72. MSRP Reservation Parameters
Field
Description
Interface
The interface associated with the rest of the information in the row.
Stream ID
A 16-bit unsigned integer value, Unique ID, used to distinguish among multiple
streams sourced by the same system.
Listener Declaration Status
The MSRP declaration status of the listener attribute.
Listener Declaration Type
The MSRP declaration type of the listener attribute.
Talker Declaration Status
The MSRP declaration status of the talker attribute.
Talker Declaration Type
The MSRP declaration type of the talker attribute.
Accumulated Latency
Identifies how much latency, in nanoseconds, the stream has suffered in its
path from the Talker to a given Listener. It starts as a 0 in a Talker Advertise
Declaration at the Talker, and its value is increased by one for each bridge as
the Talker Advertise Declaration propagates through the network.
Failure Bridge Interface
The interface on the Bridge where the failure occurred.
Failure Code
The number that represents the reason for the failure. The switch supports the
following codes:
•
1—Insufficient bandwidth
•
3—Insufficient bandwidth for the traffic class
•
5—Stream destination_address is already in use
•
7—Reported latency has changed
•
8—Egress port is not Audio/Video Bridging (AVB) capable
•
9—Use a different destination_address (i.e. MAC DA hash table full)
•
12—Cannot store destination_address (i.e., Bridge is out of MAC DA
resources)
•
13—Requested priority is not an SR Class priority
•
14—MaxFrameSize is too large for media
•
15—msrpMaxFanInPorts limit has been reached
•
16—Changes in FirstValue for a registered StreamID
•
17—VLAN is blocked on this egress port (Registration Forbidden)
Failure Bridge MAC
The MAC address of the switch where the failure occurred.
Stream Age
The time, in seconds, since the stream destination address was added to the
Dynamic Reservations Entries table. A value of zero indicates the destination
address has not been added to the table.
