6

 4.1.3

Refuelling

The refuelling operations are described in the

machine manual and are mentioned here.

To refuel:

1.

Unscrew the fuel tank filler cap

(fig.3.A) and remove it.

2.

Set a funnel on the hole. (fig.3.B)

3.

Refuel and take the funnel off (fig.3.B)

4.

At the end of refuelling, screw the cap

back on (fig.3.A) and clean any spillage.

 IMPORTANT

 Avoid getting fuel on the

plastic parts of the engine or machine to avoid

damaging them, and immediately clean off

every trace of spilled fuel. The warranty does not

cover damage to plastic parts caused by fuel.

 4.1.4

Spark plug cap

Firmly connect the cap (fig. 5.A) of the

spark plug cable (fig. 5.B), ensuring

that there are no traces of dirt inside the

cap or on the spark plug terminal.

 4.1.5

Check the battery charge status

See paragraph 5.3.2

 4.2  STARTING THE ENGINE

The engine must be started up as described

in the machine's Instructions Manual, always

being careful to uncouple any device (if

applicable) that is capable of making the

machine travel forwards or stop the engine.

 IMPORTANT

 Do not work on slopes

exceeding 20° to avoid jeopardising

correct engine operation

IMPORTANT

  Make sure the battery is

properly inserted inside its housing when dealing

with battery start-up models (par. 5.3.3

)

 4.3  STOPPING THE ENGINE AT

THE END OF OPERATION

1.

Stop the engine following the

instructions contained in the

machine's Instructions Manual.

2.

With a cold engine, take the cap off

the spark plug (fig. 5.A) and take out

the starter key (if applicable).

3.

Remove any debris from the engine

and especially around the exhaust

silencer to reduce the risk of fire.

 4.4  CLEANING AND STORAGE

•

Do not spray with water or use

pressure washer wands to clean

the exterior of the engine.

•

Preferably use a compressed air gun

(max. 6 bars), thus preventing debris

and dust from penetrating inside.

•

Store the lawnmower (and the engine)

in a dry place, sheltered from the

elements and sufficiently ventilated.

 4.5  PROLONGED DOWNTIME

If the engine is not going to be used for more than

30 days (for example, at the end of the season),

it will be necessary to take a few precautions

so that it will start back up again accordingly.

•

Start the engine and run it until it comes

to a halt, so that it uses up all the fuel that

is left in the tank and in the carburettor,

to prevent deposits forming inside.

•

Remove the spark plug and pour about 3 cl

of clean engine oil into the spark plug hole,

then, having blocked the hole with a rag, run

the starter motor briefly to turn the engine for

a few revs and distribute the oil over the inner

surface of the cylinder. Finally, replace the

spark plug without connecting the cable cap.

5.  MAINTENANCE

  Any attempt to tamper with the

emission control system may increase

emission levels above legal limits.

This definition includes the removal or

alteration of parts such as the intake system,

the fuel system and the exhaust system.

 5.1  GENERAL

  The safety regulations that must

be followed during maintenance

are described in par. 2.4.

 All controls and maintenance

operations must be carried out with

the machine off and the engine off.

Disconnect the spark plug and read the

relative instructions before starting any

cleaning or maintenance procedure. Wear

suitable clothing, gloves and glasses

before performing any maintenance.
