5

Use  of  unapproved  fuels  will  cause  damage  to

engine  components,  which  will  not  be  covered

under warranty

.

 NOTE

 Only use the fuel named in the technical

data table. Do not use other types of fuel. It is

possible to use ecological fuels, such as alkylate

petrol. The composition of this petrol has less of

an impact on people and animals. No negative

effects have been reported in connection to their

use. Nonetheless, there are types of alkylate

petrol on the market for which it is not possible

to provide specific indications on their use.

 3.7  OIL

Use always high quality oils, choosing

their viscosity grade according to

the operating temperature.

•

Only use detergent oil with a

quality of no less than SF-SG.

•

Choose the SAE viscosity based

on the technical data table.

•

The use of multigrade oil can lead to greater

consumption in hot weather, accordingly it is

necessary to check the level more frequently.

•

Do not mix oils of different brands

and characteristics.

•

SAE 30 oil, if used below +5°C, could

result in possible engine damage

due to inadequate lubrication.

 3.8  AIR FILTER

The air filter must always be in perfect

working order, to prevent debris and dust

from getting sucked into the engine, reducing

the efficiency and life of the machine.

•

Always keep the filtering element free of

debris and in perfect working order (par. 5.6).

•

If necessary, replace the filtering

element with an original spare part

Incompatible filtering elements can impair

the efficiency and life of the engine.

•

Never start the engine without mounting

the filtering element properly.

 3.9  SPARK PLUG

Not all the spark plugs for endothermic

engines are the same.

•

Use only spark plugs of the recommended

type, with the right heat range.

•

Check the length of the thread,

because - if too long - it will damage

the engine beyond repair.

•

Make sure that the electrodes are clean

and that their gap is correct (par. 5.7)

4.  REGULATIONS FOR USE

 4.1  BEFORE EACH USE

Before every use, perform the following checking

procedures in order to assure a regular operation.

 4.1.1

Oil level check

1.

Place the machine on a flat surface.

2.

Clean around the oil fill cap.

3.

Unscrew the cap(fig. 2.A), clean the end of

the dipstick (fig. 2.B) and slide it back in until

the cap is touching the hole, as shown :

–

if the dipstick is short, place the

cap without fastening it,

–

if the dipstick is long, fasten it again

with a click and then unscrew it,

4.

Remove the cap with the dipstick and

check the oil level that must be between

the «MIN» and «MAX» marks.

5.

If oil is required, add oil of the same kind

up to the «MAX» mark, being careful

not to spill any outside the oil fill

6.

Fully tighten the filler cap (fig. 2.A)

and wipe off any spilled oil.

 NOTE

 Top up gradually, adding small amounts

of oil, checking the level each time.

Do not top up beyond the «MAX» level;

an excessive level can cause:

•

smoking from the exhaust;

•

soiling of the spark plug or air filter with

subsequent difficulty for ignition.

 NOTE

 For the required type of oil, observe the

indications provided in the technical data table.

 4.1.2

Air filter control

The  efficiency  of  the  air  filter  is  essential  to  correct

engine  operation;  never  start  the  engine  if  the  filter

element is missing, broken or insufficiently saturated

with oil.

1.

   Clean around the filter cover (fig.4.A).

2.

   Remove  the  cover  (fig.  4.A)  by  releasing  the

tabs (fig. 4.B);

3

.   Check the state of the filtering element (fig. 4.C

or  4.C.1),  which  must  be  intact,  clean  and  in

perfect  working  order;  if  not,  either  carry  out

maintenance or replace it (see 5.6).

4.

  Put the cover back in place (fig. 4.A).
