Assembly

EN

WARNING:

 Always stop the engine and disconnect the spark plug

wire from the spark plug.

Removing the bump head

■

Place the holding pin through the slot in the upper flange
washer and the hole in the gear head.

■

Unlock the spool retainer as shown and remove the spool.

■

Remove the bump head from the drive connector.

■

Place the holding pin through the slot in the upper flange
washer and the hole in the gear head.

■

Turn the connector clockwise to remove.

■

Remove the washer.

WARNING:

 When using the brushcutter blade, the grass de

fl

 ector

must be removed from the blade guard.

Installing the blade

■

Place the upper flange washer over the gear shaft with the
hollow side towards the gear head.

■

Centr

e

 the blade on the upper flange, making sure the blade

sits flat.

■

Install the cupped washer with the raised centr

e

 away from the

blade.

■

Place the holding pin through the slot in the upper flange
washer and the hole in the gear head.

■

Replace the blade nut and tighten securely by turning clockwise.

CONVERTING FROM BRUSHCUTTER TO STRING
TRIMMER

WARNING:

Always stop the engine and disconnect the spark plug

wire from the spark plug.

Removing the blade

■

Place the holding pin through the slot in the upper flange
washer and the hole in the gear head.

■

Remove the blade nut, washers, and blade.

■

Attach the grass deflector to the blade deflector; align the 3
screws on the grass deflector to the screw holes on the blade
deflector.

■

Using the combination wrench supplied, tighten the two bolts
securely.

WARNING:

 When using the line trimmer bump head, the grass

de

fl

 ector must be attached to the blade guard.

Installing the bump head

■

Place the upper flange washer over the gear shaft with the
hollow side towards the gear head.

■

Place the holding pin through the slot in the upper flange
washer and the hole in the gear head.

■

Place the bump head on the drive connector.

■

Tighten securely with wrench.
