17

English (Original instructions)

DESCRIPTION

1. Primer

Bulb

2. Choke

lever

3. Fuel

Cap

4. Starter

Grip

5. Throttle

Lock

6.  On / Off Switch
7. Throttle

Trigger

8.  Rear Handle (RBC30SESB)
9.  Front Handle (RBC30SESB)
10.  S h o u l d e r   S t r a p   ( R B C 3 0 S E S B )   /   H a r n e s s
(RBC30SBSB)
11. Shaft
12. Blade Guard
13. Tri-arc Blade
14. Grass Deflector
15. Cutting Line
16.  Idle Speed Screw
17. Knob
18. Hanger Cap
19.  Trigger Handle (RBC30SBSB only)
20.  Left Handle (RBC30SBSB only)
21.  Throttle interlock (RBC30SBSB only)
22. ReelEasy

TM

23.   Latch
24.  Bolt (RBC30SBSB only)
25.  Clamp (RBC30SBSB only)
26.  Combination wrench (RBC30SBSB only)
27.   Bracket (RBC30SBSB only)
28.   Bike handle (RBC30SBSB only)
29.   Wrench
30.   Clamp
31.   Screw
32.  Bracket (RBC30SESB only)
33.   Securing bolt (RBC30SESB only)
34.  Pin (RBC30SESB only)

ASSEMBLY

Please refer to Fig. 2a - 2d.
Unpacking
This product requires assembly.

■

Carefully remove the tool and any accessories from
the box. Make sure that all items listed in the packing
list are included.

■

Inspect the tool carefully to make sure no breakage or
damage occurred during shipping.

■

Do not discard the packing material until you have
carefully inspected and satisfactorily operated the tool.

 WARNING

 If any parts are damaged or missing, do not

operate this tool until the parts are replaced.

Failure to heed this warning could result in
serious personal injury.

 WARNING

 Do not attempt to modify this product or create

accessories not recommended for use with this
product. Any such alteration or modification is
misuse and could result in a hazardous condition
leading to possible serious personal injury.

 WARNING

 To prevent accidental starting that could cause

serious personal injury, always disconnect the
engine spark plug wire from the spark plug when
assembling parts.

WARNING

 Never attach or adjust any attachment while

power head is running. Failure to stop the engine
may cause serious personal injury.

WARNING

 Be certain the knob is fully tightened before

operating equipment; check it periodically for
tightness during use to avoid serious injury.

OPERATION

FUEL AND REFUELING

HANDLING THE FUEL SAFELY

 WARNING

 Check for fuel leaks. If any are found, correct

them before using the product to prevent fire or
burn injury.

■

Always handle fuel with care, it is highly flammable.

■

Always refuel outdoors where there are no sparks
and flames. Do not inhale fuel vapors.

■

Do not let petrol or lubricant come in contact with
your skin.

■

Keep petrol and lubricant away from the eyes. If
petrol or lubricant comes in contact with the eyes,
wash them immediately with clean water. If irritation is
still present, see a doctor immediately.

■

Clean up spilled petrol immediately.

■

A l w a y s   t r a n s p o r t   a n d   s t o r e   f u e l   i n   a   c o n t a i n e r
approved for petroleum.

MIXING THE FUEL

 (Fig. 3)

■

This product is powered by a 2-stroke engine and
requires pre-mixing petrol and 2-stroke lubricant. Pre-
mix unleaded petrol and 2-stroke engine lubricant in a
clean container approved for petrol.

■

This engine is certified to operate on unleaded petrol
intended for automotive use with an octane rating
