28

 | English

Setting

– Loosen the screw

(49)

 using a cross-headed screwdriver

and align the angle indicator along the 0° mark.

– Retighten the screw.

Transport (see figure R)

Before transporting the power tool, the following steps must
be carried out:
– Bring the power tool into the transport position.
– Remove all accessories that cannot be securely fitted to

the power tool.
If possible, transport unused saw blades in a closed con-
tainer.

– Carry the power tool by the transport handle

(3)

 or hold it

by the recessed handles

(20)

 on the sides of the saw

table.

u

Only use the transport devices to transport the power
tool and never the protective devices.

Maintenance and Service

Maintenance and Cleaning

u

Pull the plug out of the socket before carrying out any
work on the power tool.

u

To ensure safe and efficient operation, always keep
the power tool and the ventilation slots clean.

In order to avoid safety hazards, if the power supply cord
needs to be replaced, this must be done by

Bosch

 or by an

after-sales service centre that is authorised to repair

Bosch

power tools.
The retracting blade guard must always be able to move
freely and retract automatically. It is therefore important to
keep the area around the retracting blade guard clean at all
times.
Always remove dust and chips after working by blowing out
with compressed air or using a brush.
Clean the guide roller

(26)

 regularly.

Cleaning the laser lens (see figure S)

– Swivel the retracting blade guard

(9)

 to the back and hold

it in this position.

– Loosen the knurled screw

(50)

 for the laser protection

cap

(7)

.

– Pull the clear laser lens cover

(51)

 forwards and out of

the laser protection cap and wipe off any dirt using a dry,
soft cloth.

– Reinsert the cover

(51)

 in the laser protection cap as far

as it will go

(7)

 and retighten the knurled screw

(50)

.

Accessories

Article number

Extension bar

  1 619 PB6 147

Dust bag

 1 619 PB6 246

Saw blades for wood and fibreboard, panels and strips

Article number

216 x 30 mm saw blade, 48 teeth

 2 608 640 432

Saw blades for plastic and non-ferrous metals

216 x 30 mm saw blade, 60 teeth

 2 608 640 446

Saw blades for all types of laminate flooring

216 x 30 mm saw blade, 60 teeth

 2 608 642 133

After-Sales Service and Application Service

Our after-sales service responds to your questions concern-
ing maintenance and repair of your product as well as spare
parts. You can find explosion drawings and information on
spare parts at:

www.bosch-pt.com

The Bosch product use advice team will be happy to help you
with any questions about our products and their accessor-
ies.
In all correspondence and spare parts orders, please always
include the 10‑digit article number given on the nameplate
of the product.

Great Britain

Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham Uxbridge
UB 9 5HJ
At www.bosch-pt.co.uk you can order spare parts or arrange
the collection of a product in need of servicing or repair.
Tel. Service: (0344) 7360109
E-Mail: boschservicecentre@bosch.com

You can find further service addresses at:

www.bosch-pt.com/serviceaddresses

Disposal

The power tool, accessories and packaging should be re-
cycled in an environmentally friendly manner.

Do not dispose of power tools along with
household waste.

Only for EU countries:

According to the European Directive 2012/19/EU on Waste
Electrical and Electronic Equipment and its implementation
into national law, power tools that are no longer usable must
be collected separately and disposed of in an environment-
ally friendly manner.

1 609 92A 6DZ | (15.03.2021)
