Mounting holes

(20)

Recessed handles

(21)

Extension bar

(22)

Screw clamp

(23)

Adjustable fence

(24)

Scale for bevel angle

(25)

Angle indicator (vertical)

(26)

Guide roller

(27)

Chip deflector

(28)

Spindle lock

(29)

On/off switch

(30)

On/off switch for laser (cutting line indication)

(31)

Chip ejector

(32)

Hex key

(33)

Clamping handle for various bevel angles

(34)

Transport safety lock

(35)

Holes for screw clamp

(36)

Wing bolt for fixing the guide rail for length gauge

(37)

Guide rail for length gauge

(38)

Securing screw for extension bar

(39)

Hex socket screw for mounting the saw blade

(40)

Clamping flange

(41)

Saw blade

(42)

Inner clamping flange

(43)

Wing bolt for fixing the adjustable fence

(44)

Wing bolt for adjusting the height of the threaded
rod

(45)

Threaded rod

(46)

Clamping screw for length gauge

(47)

Screws for insert plate

(48)

Hex socket screw for fence

(49)

Screw for mitre angle indicator

(50)

Knurled screw for laser protection cap

(51)

Laser lens cover

Technical Data

Mitre saw

GCM 216

Article number

 3 601 M33 0..

Rated power input

W

1300

No-load speed

min

-1

4800

Laser type

nm

650

mW

< 1

Laser class

2

Divergence of laser line

mrad

(full

angle)

1.0

Mitre saw

GCM 216

Weight according to EPTA-Pro-
cedure 01:2014

kg

9.1

Protection class

 / II

Dimensions of suitable saw blades

Saw blade diameter

mm

216

Base blade thickness

mm

1.4−1.8

Max. cutting width

mm

3.3

Hole diameter

mm

30

Permitted workpiece dimensions (maximum/minimum): (see "Per-
missible workpiece dimensions", page 27)
The specifications apply to a rated voltage [U] of 230 V. These spe-
cifications may vary at different voltages and in country-specific mod-
els.
Only for power tools without starting current limitation: Switching
these on causes the voltage to drop briefly. Other tools may be ad-
versely affected by these if the conditions in the electricity supply are
unfavourable. Malfunctions are not to be expected for system imped-
ances below

0.35

 ohm.

Noise Information

Noise emission values determined according to

EN 62841-3-9

.

Typically, the A-weighted noise level of the power tool is:
Sound pressure level

96

 dB(A); sound power level

106

 dB(A). Uncertainty K =

3

 dB.

Wear hearing protection!

The noise emission value given in these instructions has
been measured in accordance with a standardised measur-
ing procedure and may be used to compare power tools. It
may also be used for a preliminary estimation of noise emis-
sions.
The noise emission value given represents the main applica-
tions of the power tool. However, if the power tool is used
for other applications, with different application tools or is
poorly maintained, the noise emission value may differ. This
may significantly increase noise emissions over the total
working period.
To estimate noise emissions accurately, the times when the
tool is switched off, or when it is running but not actually be-
ing used, should also be taken into account. This may signi-
ficantly reduce noise emissions over the total working
period.

Assembly

u

Avoid starting the power tool unintentionally. The
mains plug must not be connected to the power supply
during assembly or when carrying out any kind of
work on the power tool.

Items included

See the list of items included at the start of
the operating manual.
