English

-

1

Please read and comply with these
original instructions prior to the ini-

tial operation of your appliance and store them
for later use or subsequent owners.

Ensure that gear oil is not released into the
environment.  Protect the ground and dis-
pose of used oil in an environmentally-
clean manner.
Do not let waste water containing mineral
oil spill into the soil, into waters or without
treatment into the discharge channel. Ob-
serve the locally valid regulations and
waste water by-laws

Notes about the ingredients (REACH)

You will find current information about the
ingredients at:

www.kaercher.com/REACH

To avoid danger to persons, animals and
property  before the first operation of the
system, read:

–

the operating manual

–

all safety instructions

–

the respective national statutes of the
legislator

–

the safety instructions which are at-
tached to the used detergents (normally
on the packing label).

For the operation of this system the follow-
ing regulations and directives are applica-

ble in the Federal Republic of Germany
(available from Carl Heymanns Verlag KG,
Luxemburger Straße 449, 50939 Cologne):

–

Accident prevention provision "General
rules and regulations" BGV A1

–

Safety for vehicle wash plants DIN
24446

–

Order in respect of operational safety
(BetrSichV).

Ensure:

–

that you have understood all the in-
structions

–

that all users of the plant are informed
about the instructions and have under-
stood them.

The following symbols are used in this op-
erating manual:



Danger

Immediate danger that can cause severe
injury or even death.

몇

Warning

Possible hazardous situation that could
lead to severe injury or even death.

Caution

Possible hazardous situation that could
lead to mild injury to persons or damage to
property.

Only persons may be entrusted with the op-
eration, monitoring, servicing, maintenance
and checking of the vehicle washing plants
who are familiar with these works and are
acquainted with the operating manual, and
who have been instructed about the dan-
gers involved with the plant.

Self-service vehicle wash plants must have
a person available on operational standby
who is familiar with the plant and, in the
event of an operational failure, who is able
to perform, or arrange for, the necessary
measures to avoid possible dangers. In-
structions concerning the operation and in-
tended use of the plant must be posted
where they can be easily seen at the wash-
ing place.

To avoid damage to the vehicles and the
plant, only private cars and closed trucks
may be cleaned according to the specifica-
tions in the section "Technical Data/Dimen-
sions", vehicle dimensions.

Maintenance work may be carried out only
when the plant is switched off. In this case
the main switch must be protected against
unauthorized restarting (attach padlock at
the main switch).

Take protective measures when handling
cleaning agent concentrates which contain
hazardous substances. Especially gog-
gles, protective gloves and personal pro-
tective clothing must be worn and the
instruction leaflets/safety data sheets at-
tached to the detergents have to be ob-
served.

Unauthorized persons may not enter the
vehicle washing plant. The entry prohibition
is to be indicated continually and in a clear-
ly recognisable way.

Danger of slipping in the plant from mois-

ture on the floor and on the plant sections.

Move with care when working on the plant

and wear suitable footwear. Washing cus-

tomers must be warned of the danger of

slipping through suitable notices.

몇

Warning

To avoid danger through false operation, the
plant must be operated only by persons,who

–

are instructed in its operational handling

–

have proved their capabilities in respect of
operation

–

have been explicitly commissioned to use
it.

The operating manual must be made avail-
able to each user. The plant may not be op-
erated by persons under 18 years old.
Trainees over 16 years old and under su-
pervision are exceptions here.

This wash plant is designed for the exterior

cleaning of private cars with standard

equipment and closed lorries according to

the section "Technical Data/Dimensions",

vehicle size limits. Included in the intended

use are also the following:

–

observing all instructions in this operat-

ing manual and

–

the compliance with the inspection and

maintenance instructions.

Caution

Risk of damage. When using Carlite brushes,

the vehicle must be manually cleaned before-

hand, if the appliance is not equipped with an

upgrade kit high pressure!

The plant must be set up by qualified skilled
personnel. When setting up the plant, appli-
cable local safety regulations must be ob-
served (i.e. distances between the plant
and building).

몇

Warning

Danger of damage from ice forming in the

plant. The water must be drained from the

plant when there is a danger of frost. The

circulation routes for customers using the

washing plant must remain slip-resistant

(e.g. using underfloor heating, gravel).

Caution

Increased risk of corrosion by using inap-
propriate detergents.
The following detergents must not be proc-
essed by the installation:

–

detergents intended for the cleaning of
the wash hall.

–

detergents intended for the exterior

cleaning of the washing system.

–

Acid-containing detergents.

–

Detergents which are applied to the ve-

hicle by a separate device (such as rim

cleaners).

–

Detergents to treat wastewater.

Contents

Before Startup. . . . . . . . . . .

EN  . .  1

System description . . . . . . .

EN  . .  3

Control elements. . . . . . . . .

EN  . .  4

Technical specifications  . . .

EN  . .  6

Operation  . . . . . . . . . . . . . .

EN  . .  6

Shutting down . . . . . . . . . . .

EN  . .  7

Maintenance and care  . . . .

EN  . .  8

Faults  . . . . . . . . . . . . . . . . .

EN  .  13

Before Startup

Environmental protection

The packaging materials are re-
cyclable. Please do not throw
packaging in the domestic
waste but pass it on for recy-
cling.
Old units contain valuable recy-
clable materials. Batteries, oil
and similar substances may not
be released into the environ-
ment. Therefore please dispose
of old units through suitable col-
lection systems.

A battery in the control unit sup-
plies the system clock with pow-
er in the event of a power failure.
Batteries contain substances
that must not enter the environ-
ment. Please dispose of your
batteries using appropriate col-
lection systems.

Safety instructions

General

Vehicle washing plants

Self-service

Intended use

Maintenance

hazardous materials

Entering the vehicle washing plant

Danger of slipping

Operation of the plant

Proper use

23

EN
