 Display status indicators (LCD panel)

 Inserting the battery

 This recorder uses a lithium ion
battery specified by Olympus (LI-42B).
Do not use any other type of battery.

1

 Lightly press down on the battery
cover release button, then open
the battery cover, as shown in the
illustration below.

0
!

#

@

%

$

1

2

9

4
5

6

7
8

3

 Display in the recording mode

 Display in the playback mode

1

   Current file name

2

   Current  folder

3

   Current file number/ Total

number of recorded files in
the folder

4

   Recording elapsed time

5

   Remaining memory bar

indicator

6

   Remaining recording time

7

   Level meter indicator

8

   Button guide display

9

   Recorder status indicator

0

   Current playback time

!

   Index mark indicator

@

   Playback position bar

indicator

#

   Verbal comment indicator

$

   File  length

%

   Recording date and time

^

   Slide switch guide

 You can display the slide switch
guide by using “

Slide switch

guide

 ” of the customize functions

of ODMS software.

&

   File information area

 Current file’s information can be
displayed by using the “

Display

 ”

function in the ODMS software.

   [ ]: SD card
   [

]: SD Card lock

   [

]: microSD card

   [

]: Microphone

sensitivity

   [

]: Recording mode

   [

]: Battery

   [

]: VCVA (Variable

Control Voice Actuator)

   [ ]: Pending
   [

]: Encryption

   [ ]: Priority
   [ ]: File lock
   [ ]: Author ID
   [ ]: Work Type
   [

]: Option Item

2

   Insert the battery observing the

correct polarity as shown in the
illustration, then close the battery
cover.

 •  Insert the battery by sliding in

direction

A

  while pushing down

in direction

B

 .

 Battery  indicator:

 The battery indicator on the display
will decrease as the battery loses
power.

 •  When this [

] indicator appears

on the display, charge the battery
as soon as possible. When the
battery is too weak, [

s

 ]  and

[

Battery Low

 ] will appear on the

display and the recorder will shut
down.

 Notes:

 •  Turn off the recorder before

removing the battery. Removing
the battery while the recorder is still
in use may cause malfunctions, file
corruption or file loss.

 •  Remove the battery if you are not

going to use the recorder for an
extended period of time.

 •  After removing the battery, it may

become necessary to re-set the
time and date if you leave the
battery out of the recorder for more
than 15 minutes or if you remove
the battery right after loading it into
the recorder.

^

&

 Display in the recording mode

&

POWER

   (

ON

 /

OFF

 )  switch

*

EAR

  (Earphone) jack

(

MIC

  (Microphone) jack

)

   USB  connector

-

   Docking station connector
