42

 | English

1 609 92A 1T0 | (28.10.15)

Bosch Power Tools

blade) agrees with the direction of the arrow on the
casing!

– Place on the clamping flange

14

 and the screw

12

.

Press the spindle lock

13

 until it engages and tighten the

screw turning in anticlockwise direction.

– Push the lever

11

 downward and, at the same time, rotate

the retracting blade guard

20

 downward again until the le-

ver engages.

– Screw in and tighten the locking screw

10

 again.

Transport (see figure g)



Before any work on the machine itself, pull the mains
plug.

Before transporting the power tool, the following steps must
be carried out:

– Bring the power tool into the table saw working position.

(see “Working Position”, page  47)

– Position the parallel guide

61

 completely over the protec-

tion guard

63

.

To lock the parallel guide, push the clamping knob

64

downward.

– Attach the hold-down stick onto the pins

67

.

– Insert the lower saw blade cover

66

 into the saw table

22

.

– Remove all accessories that cannot be mounted firmly to

the power tool.
If possible, place unused saw blades in an enclosed con-
tainer for transport.

– For lifting or transporting, hold the power tool by the re-

cessed grips

4

 on the side of the saw table

22

.



The power tool should always be carried by two per-
sons in order to avoid back injuries.



When transporting the power tool, use only the trans-
port devices and never use the protective devices.

Operation as Chop and Mitre
Saw



Before any work on the machine itself, pull the mains
plug.

Working Position (see figure

A)

If the power tool is still in the condition as delivered or if the
power tool was used as a table saw, then the following steps
must be carried out before using as a chop and mitre saw:

– Loosen both clamping levers

68

 below the saw table

59

.

– Pull the saw table upward to the stop.
– Hold the saw table in this position and tighten the clamping

levers again.

– Position the parallel guide

61

 over the saw blade as a pro-

tective measure.

– Push the tool arm by the handle

18

 down a little in order to

relieve the transport safety-lock

38

.

– Pull the transport safety-lock

38

 completely outward.

– Remove the lower saw blade cover

66

 and slide it into the

groove on the right-hand side of the parallel guide

61

.



Do not throw away the lower saw blade cover!

If the low-

er saw blade cover is not used, it is not possible to operate
the combination saw as a table saw!

– Guide the tool arm slowly upward.
–

Loosen

 locking screw

44

.

– Slide the adjustable fence

31

 completely inward.

– Retighten the locking screw

44

.

Preparing for Operation

Extending the Saw Table (see figure

B)

Long workpieces must be underlaid or supported at their free
end.

– Loosen both hex socket screws

41

 with the hex key

5

 pro-

vided.

– Pull out the saw table extension

29

 to the stop and tighten

the hex socket screws again.

Clamping the Workpiece (see figure

C)

To ensure optimum working safety, the workpiece must al-
ways be firmly clamped.
Do not saw workpieces that are too small to clamp.

– Press the workpiece firmly against the fence

30

.

– Insert the material clamp

21

 provided into one of the holes

28

 intended for it.

– Loosen the wing bolt

43

 and adapt the material clamp to

the workpiece. Tighten the wing bolt again.

– Firmly clamp the workpiece by turning the threaded rod

42

 in clockwise direction.

Moving the Fence (see figure

D)

You have to move the adjustable fence

31

 to saw bevel an-

gles.

–

Loosen

 locking screw

44

.

– Pull the adjustable fence

31

 completely outward.

– Retighten the locking screw

44

.

After sawing the bevel angles, slide the adjustable fence

31

back again (loosen the locking screw

44

; slide the fence

31

completely inward; retighten the locking screw).

Adjusting the Cutting Angle

To ensure precise cuts, the basic adjustment of the machine
must be checked and adjusted as necessary after intensive
use (see “Checking and Adjusting the Basic Adjustment”,
page 45).



Always tighten the locking knob 25 firmly before saw-
ing.

Otherwise the saw blade can become wedged in the

workpiece.

– Bring the power tool into the chop and mitre saw working

position.  (see “Working Position”, page 42)

Adjusting Standard Mitre Angles
 (see figure

E)

For quick and precise adjustment of commonly used mitre an-
gles, detents

27

 have been provided for on the saw table:

Left

Right

0 °

45 °

31.6 °

22.5° 15 °

15 °

22.5 °

31.6 °

45 °
