English

13

THICK

LOG,

L ARGER

THAN

GUIDE

BAR

LENGTH

Begin by cutting on the opposite side of the log. Pull the saw towards
you, followed by previous procedure. (

Fig.

26

)

If the log is lying on the ground make a boring cut to avoid cutting into
the ground. Finish with a bottom cut. (

Fig.

27

)

WARNING

KICKBACK

DANGER

Do not attempt a boring cut if you are not properly trained. A
boring cut involves the use of the nose of the guide bar and can
result in kickback.

CROSS

CUT TING

LOGS,

PRESSURE

ON

BOT TOM

Take a

fi

 rm stance. Begin with a bottom cut. The depth of the cut

should be about 1/3 of the log diameter.
Finish with an upper cut. The saw cuts should meet. (

Fig.

28

)

29. Relieving cut
30. Cross cut
31.  Pressure on bottom
32. Tension side
33. Pressure side
34.  Relative depth of saw cuts

THICK

LOG,

L ARGER

THAN

GUIDE

BAR

LENGTH

Begin by cutting on the opposite side of the log. Pull the saw towards
you, followed by previous procedure. Make a boring cut if the log is
close to the ground. Finish with a top cut. (

Fig.

29

)

WARNING

KICKBACK

DANGER

Do not attempt a boring cut if you are not properly trained. A
boring cut involves the use of the nose of the guide bar and can
result in kickback. (

Fig.

30

)

IF

THE

SAW

GETS

STUCK

Stop the engine. Raise the log or change its position, using a thick branch
or pole as a lever. Do not try to pull the saw free. If you do, you can deform
the handle or be injured by the saw chain if the saw is suddenly released.

MAINTENANCE

MAINTENANCE, REPL ACEMENT OR REPAIR OF THE EMISSION
CONTROL DEVICES AND SYSTEM MAY BE PERFORMED BY ANY
NON-ROAD ENGINE REPAIR ESTABLISHMENT OR INDIVIDUAL.

Carburetor

adjustment

(Fig.

31)

WARNING

Never star t the engine without the complete side case.

Otherwise the clutch can come loose and cause personal injuries.

In the carburetor, fuel is mixed with air. When the engine is test run at
the factor y, the carburetor is adjusted. A fur ther adjustment may be
required, according to climate and altitude. The carburetor has one
adjustment possibility:
T = Idle speed adjustment screw.

Idle

speed

adjustment

(T)

Check that the air

fi

 lter is clean. When the idle speed is correct, the

cutting attachment will not rotate. If adjustment is required, close
(clockwise) the T-screw, with the engine running, until the cutting
attachment star ts to rotate. Open (counter-clockwise) the screw
until the cutting attachment stops. You have reached the correct idle
speed when the engine runs smoothly in all positions well below the
rpm when the cutting attachment star ts to rotate.
If the cutting attachment still rotates after idle speed adjustment,
contact HITACHI dealer.

WARNING

When the engine is idling the cutting attachment must under no
circumstances rotate.

NOTE

Some  models  sold  in  areas  with  strict  exhaust  emission
regulation do not have high and low speed carburetor
adjustments. Such adjustments may allow the engine to be
operated outside of their emission compliance limits. For these
models, the only carburetor adjustment is idle speed.

If you are not familiar with this type of adjustment, please ask for
assistance from your HITACHI dealer.

Air

 fi

lter

(Fig.

32)

The air

fi

 lter (37) and cleaner sponge (36), (38) must be cleaned from

dust and dir t in order to avoid:

○

 Carburetor

malfunctions.

○

 Star ting

problems.

○

  Engine power reduction.

○

  Unnecessar y wear on the engine par ts.

○

  Abnormal fuel consumption.

Clean the air

fi

 lter daily or more often if working in exceptionally

dusty areas.

Cleaning

the

air

 fi

lter

Remove the air

fi

 lter cover (35) and the cleaner sponge (36). Turn the

air

fi

 lter (37) 20° counter-clockwise and remove. Then remove the

cleaner sponge (38).
Rinse them in warm soap suds. Check that the

fi

 lter is dr y before

reassembly. An air

fi

 lter that has been used for some time cannot be

cleaned completely. Therefore, it must regularly be replaced with a
new one. A damaged

fi

 lter must always be replaced.

Spark

plug

(Fig.

33)

The spark plug condition is in

fl

 uenced by:

○

  An incorrect carburetor setting.

○

  Wrong fuel mixture (too much oil in the gasoline)

○

  A dir ty air

fi

 lter.

○

  Hard running conditions (such as cold weather).

These factors cause deposits on the spark plug electrodes, which
may result in malfunction and star ting di

ffi

  culties. If the engine is

low on power, di

ffi

  cult to star t or runs poorly at idling speed, always

check the spark plug

fi

 rst. If the spark plug is dir ty, clean it and check

the electrode gap. Readjust if necessar y. The correct gap is 0.6 mm.
The spark plug should be replaced after about 100 operation hours
or earlier if the electrodes are badly eroded.

NOTE

In some areas, local law requires using a resistor spark plug to
suppress ignition signals. If this machine was originally equipped
with resistor spark plug, use same type of spark plug for replacement.

Oiler

port

(Fig.

34)

Clean the chain oiler por t (39) whenever possible.

Guide

bar

(Fig.

35)

Before using the machine, clean the groove and oiler por t (40) in the
bar with the special gauge o

ff

  ered as an optional accessor y.

Side

case

(Fig.

36)

Always keep the side case and drive area clean of saw dust and
debris. Periodically apply oil or grease to this area to protect from
corrosion as some trees contain high levels of acid.

Fuel

 fi

lter

(Fig.

37)

Remove the fuel

fi

 lter from the fuel tank and thoroughly wash it in

solvent. After that, push the

fi

 lter into the tank completely.

NOTE

 If

the

fi

 lter is hard due to dust and dir t, replace it.

Chain

oil

 fi

lter

(Fig.

38)

Remove the oil

fi

 lter and thoroughly wash it in solvent.

After that, push the

fi

 lter into the tank completely.

NOTE

 If

the

fi

 lter is hard due to dust and dir t, replace it.

For

long-term

storage

Drain all fuel from the fuel tank. Star t and let engine run until it stops.
Repair any damage which has resulted from use. Clean the unit with
a clean rag, or the use of high pressure air hose. Put a few drops of
two-cycle engine oil into the cylinder through the spark plug hole,
and spin the engine over several times to distribute oil.
Cover the unit and store it in a dr y area.

CHAIN

SHARPENING

Parts

of

a

cutter

(Fig.

39,

40)

WARNING

○

  Gloves should be used when sharpening chain.

○

  Be  sure  to  round  o

ff

  the front edge to reduce the chance of

kickback or tie-strap breakage.
