Bosch MUM 58K20 - Инструкция по эксплуатации - Страница 24

24 

en

Operation 

Warning!

The grating disc is not suitable for grating 

soft cheese and cheese slices.

Working with the continuous-feed

shredder

Fig.

G

:

■ Press the Release button and 

move the swivel arm to position 

2

.

■ Insert the bowl: 

Tilt the bowl forwards and then set 

it down. Turn anti-clockwise until it locks 

into place.

■ Press the Release button and 

move the swivel arm to position 

3

.

■ Remove drive cover from the 

drive of the continuous-feed shredder 

(Fig.

G

-5a)

.

■ Hold disc holder at the lower end, ensuring 

that the two tips are face up.

■ Carefully place the required slicing or 

shredding disc onto the tips of the disc 

holder 

(Fig.

G

-6a)

. 

In the case of reversible discs, ensure that 

the required side is face up.

■ Grip disc holder at the upper end and 

insert into the housing 

(Fig.

G

-6b)

.

■ Attach the cover (note mark) and turn all 

the way in a clockwise direction.

■ Place continuous-feed shredder on the 

drive and rotate all the way in a clockwise 

direction, as illustrated in 

Fig.

G

-8

.

■ Turn rotary switch to recommended 

setting.

■ Put food to be processed in the feed tube 

and push down with the pusher.

Warning!

Prevent the cut ingredients from building up 

in the outlet opening.

Tip:

 To ensure even cutting results, process 

thin ingredients in bunches.

Note:

 If the food to be processed sticks in 

the continuous-feed shredder, switch food 

processor off, pull out mains plug, wait until 

the drive comes to a standstill, remove cover 

from the continuous-feed shredder and 

empty feed tube.

After using the appliance

■ Switch off the appliance with the rotary 

switch.

■ Rotate the continuous-feed shredder in an 

anti-clockwise direction and remove.

■ Rotate the lid in an anti-clockwise direction 

and remove.

■ Remove disc holder with disc. To do this, 

press finger from below against the drive 

shaft 

(Fig.

H

)

.

■ Clean parts.

Blender

W

Risk of injury from sharp blades /

rotating drive!

Never place fingers in the attached blender! 

Do not remove / attach the blender until the 

drive is at a standstill! Operate the assem-

bled blender only and with the lid attached.

W

Risk of scalding!

If processing hot liquids, steam escapes 

through the funnel in the lid. Add a 

max. 0,5 litres of hot or frothing liquid.

Warning!

Blender may be damaged. Do not process 

deep-frozen ingredients (except ice cubes). 

Do not operate blender when empty.

Working with the blender

Fig.

J

:

■ Press the release button and 

move the swivel arm to position 

4

.

■ Remove the blender drive cover.

■ Attach blender jug (mark on the handle on 

mark on the base unit) and turn all the way 

in an anti-clockwise direction.

■ Add ingredients. 

Maximum amount of liquid = 1.25 litres; 

maximum amount of frothing or hot liquids 

= 0.5 litres; 

Optimal processing capacity –  

solids = 50-100 g;

■ Attach the cover and turn anti-clockwise all 

the way into the blender handle. The cover 

must be locked in position.

■ Set the rotary switch to the desired setting.
