21

en

Operating positions

9  Drive for blender

 (optional accessory*) 

When not in use, attach the blender drive 

cover.

10  Cord store

MUM52../MUM54../MUM58..:

Stow the cord in the cord store 

MUM55../MUM56..:

Automatic cord winder

Bowl with accessories

11  Stainless steel stirring bowl

12  Lid
Tools

13  Stirrer

14  Whisk

15

Kneading hook with dough deflector

16  Accessories bag

For storage of the tools and cutting discs.

Continuous-feed shredder

17  Pusher

18

Cover with filling shaft

19  Cutting discs

a

Reversible slicing disc – thick / thin

b

Reversible shredding disc –  

coarse / fine

c

Grating disc – medium-fine

20  Disc holder

21  Housing with outlet opening
Blender*

22  Blender jug

23  Lid

24  Funnel

* If an accessory is not included in the 

product package, it can be purchased via the 

trade or customer service.

Operating positions

Fig.

B

:

Attention!

Before operating the appliance, attach the 

tool / accessory to the correct drive and 

in the correct position and place in the 

operating position according to this table. 

The swivel arm must be engaged in every 

operating position.

Note

The swivel arm features an “Easy Armlift” 

function which supports the upwards move-

ment of the swivel arm.

Selecting the operating position:

■ Press the Release button and move the 

swivel arm. Support movement with your 

hand.

■ Move the swivel arm until it engages in the 

required position.

Position

Drive

MUM52.. MUM

54/55/

56/58..

1

7

1-4

1-7

1-4

1-7

1-2

1-3

2

7

*

–

–

3

6

2-4

3-7

2-3

3-5

4

9

3-4

5-7

7

3-4

5-7

* Insert / remove whisk, stirrer or kneading 

hook. Add large quantities of ingredients.
