30

 | English

1 609 92A 039 | (28.9.12)

Bosch Power Tools

15

OFF button

16

Angle stop

17

Ring spanner (23 mm; 13 mm)

18

Auxiliary stop of the angle stop

16

19

Fastening screw of saw-blade storage

20

Mounting holes

21

Guide groove for angle stop

22

Push stick

23

Fastening knob for table extension

2

24

Locking lever of the sliding table

25

Fastening knob for parallel fence

9

26

Fastening knob for table width enlargement

10

27

Storage for auxiliary stop

18

28

Storage for parallel guide

8

29

Locking knob for adjustment of bevel angles

30

Cable holder

31

Sawdust ejector

32

Storage for angle stop

33

Vacuum hose

34

Bottom plate

35

Hexagon bolt for fastening of the riving knife

4

36

Insert-plate notches

37

Saw blade

38

Fixture for riving knife

39

Fastening kit for “table extension”

40

Rubber buffer

41

Guide rail of the angle stop

42

Locking knob on the angle guide

43

Fastening kit “for auxiliary stop/angle stop”

44

Clamping handle of the parallel guide

45

Guide groove for parallel guide

8

46

Clamping lever of auxiliary stop

7

47

Spindle lock lever

48

Clamping nut

49

Clamping flange

50

Mounting flange

51

Tool spindle

52

Locking knob for bevel angle (horizontal)

53

Angle indicator on the angle guide

54

Handwheel

55

Indicator for bevel angle

56

Scale for bevel angle

57

Lens

58

Scale for clearance of the saw blade to the parallel fence

9

59

Adjusting screw for setting the standard 90 °  bevel angle

60

Adjusting screw for setting the standard 45 °  bevel angle

61

Screw for bevel angle indicator

62

Nut for adjustment of the parallel-fence

8

 tensioning

force

63

Adjusting screws for sliding-table play

64

Adjusting screws for insert plate

65

Recessed handles

66

Fastening kit for “base unit” *

67

Base unit *

* Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.

Technical Data

Noise Information

Measured sound values determined according to EN 61029.

Typically the A-weighted noise levels of the product are:
Sound pressure level 91 dB(A); Sound power level
104 dB(A). Uncertainty K = 3 dB.

Wear hearing protection!

Declaration of Conformity

We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with the fol-
lowing standards or standardization documents: EN 61029
according to the provisions of the directives 2011/65/EU,
2004/108/EC, 2006/42/EC.

EC Type Examination No. 4811001.11001 by notified test-
ing agency No. 2140.

Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ETM9,
D-70745 Leinfelden-Echterdingen

Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
Leinfelden, 28.09.2012

Table saw

PTS 10

Article number

3 603 M03 4..

Rated power input

W

1400

No-load speed

min

-1

5000

Reduced starting current



Weight according to
EPTA-Procedure 01/2003

kg

26

Protection class

/

II

Dimensions (incl. removable product features)

Width x depth x height

mm 620 x 770 x 450

Maximum workpiece dimensions, see page 34.
The values given are valid for a nominal voltage [U] of 230 V. For differ-
ent voltages and models for specific countries, these values can vary.

Dimension of suitable saw blades

Saw blade diameter

mm

254

Blade body thickness

mm

1.8

Tooth thickness/setting, min.

mm

2.5

Mounting hole diameter

mm

30

Dr. Egbert Schneider
Senior Vice President
Engineering

Helmut Heinzelmann
Head of Product Certification
PT/ETM9
