21

English

CAUTION

  Be absolutely sure to insert the nail of the carbon brush

into the contact portion of brush tube. (You can insert
whichever one of the two nails provided.)

  Caution must be exercised since any error in this

operation can result in the deformed nail of the carbon
brush and may cause motor trouble at an early stage.

5.



Cleaning



of



the



outside



When the grass trimmer is stained, wipe with a soft dr y
cloth or a cloth moistened with soapy water. Do not use
chloric solvents, gasoline or paint thinner, as they melt
plastics.

6.



Storage



Store grass trimmer in a place in which the temperature
is less than 40°C and out of reach of children.

NOTE



Make sure that the batter y is fully charged when stored
for a long period (3 months or more). The batter y with
smaller capacity may not be able to be charged when
used, if stored for a long period.

7.



Service



parts



list

CAUTION



Repair, modi

 cation and inspection of Hitachi Power

Tools must be carried out by a Hitachi Authorized
Ser vice Center.



This Parts List will be helpful if presented with the tool to
the Hitachi Authorized Ser vice Center when requesting
repair or other maintenance.



In the operation and maintenance of power tools, the
safety regulations and standards prescribed in each
countr y must be obser ved.

MODIFICATIONS



Hitachi Power Tools are constantly being improved
and modi

 ed to incorporate the latest technological

advancements.



Accordingly, some parts may be changed without prior
notice.

Important



notice



on



the



batteries



for



the



Hitachi



cordless



power



tools

Please always use one of our designated genuine
batteries. We cannot guarantee the safety and
performance of our cordless power tool when used with
batteries other than these designated by us, or when
the batter y is disassembled and modi

 ed (such as

disassembly and replacement of cells or other internal
parts).

OPERATIONAL



CAUTIONS

Continuous



work



This tool comes with an over-heat protection circuit
that protects the electronic parts that control the
rechargeable batter y. In continuous trimming work, tool
temperature will rise and eventually trigger the over-
heat protection circuit, which will shut down the tool.



If this happens, let the tool cool for a length of time.
When the temperature drops, it will again become
possible to use the tool. When the rechargeable batter y
has to be exchanged during continuous operation, let
the tool rest for about 15 minutes.

Overload



Protection



This  tool  comes  with  an  overload  protection  circuit
to protect the electronic parts controlling the tool. In
continuous overload during trimming work (locking the
nylon head, etc.), the overload protection circuit shuts
down the motor. If this happens, turn OFF the power,
and then resolve the problem causing the overload.



The power lamp blinks if the lever is pressed after the
motor has stopped (see page 19, “ABOUT POWER
LAMP ”). The power automatically turns OFF if the
power  lamp  blinks  longer  than  5  seconds.  If  this
happens, resolve the problem causing the overload,
and then switch the power button ON to resume using
the tool.

MAINTENANCE



AND



INSPECTION

CAUTION

  Pull out batter y before doing any inspection or

maintenance.

1.



Checking



the



condition



of



the



nylon



head



The nylon head should be checked regularly. If worn or
broken nylon head can slip or decrease the e

  ciency of

the motor and burn it out.



Replace worn nylon head with new ones.

CAUTION



If you use a nylon head of which point is worn or broken,
it will be dangerous. So replace it with a new one.

2.



Check



the



Screws



Loose screws are dangerous. Regularly inspect them
and make sure they are tight.

CAUTION



Using this power tool with loosened screws is extremely
dangerous.

3.



Inspecting



the



carbon



brushes



(Fig.



28)

  The motor employs carbon brushes which are

consumable parts. Since and excessively worn carbon
brush can result in motor trouble, replace the carbon
brush with new ones when it becomes worn to or
near the “wear limit ”. In addition, always keep carbon
brushes clean and ensure that they slide freely within
the brush holders.

NOTE



When replacing the carbon brush with a new one, be
sure to use the Hitachi Carbon Brush Code No. 999015.

4.



Replacing



carbon



brushes



Take out the carbon brush by

 rst removing the brush

cap and then hooking the protrusion of the carbon
brush with a slotted head screw driver, etc., as shown
in

Fig.



29

.



When installing the carbon brush, choose the direction
so that the nail of the carbon brush (see

Fig.



30

) agrees

with the contact portion of brush tube. Then push it in
with a

 nger as illustrated in

Fig.



31

. Lastly, install the

brush cap.
