MAINTENANCE

Lubrication

Lubricate the unit at the locations shown in Figures 16-19
as well as the lubrication points listed. Generally, all moving
metal parts should be oiled where contact is made with
other parts. Keep oil and grease off belts and pulleys.
Wipe surfaces clean before and after lubrication.

Seat Adjustment

The seat can be adjusted forward and back. Move the lever

(

A

, Figure 20), position the seat as desired, and release

the lever to lock the seat into position.

Brake Adjustment

This unit does not have a manually adjustable brake. If the
brake does not function properly, see an authorized dealer.

Changing the Oil

Used oil is a hazardous waste product and must be dis-
posed of properly. Do not discard with household waste.
Check with your local authorities, service center, or dealer
for safe disposal/recycling facilities.

27

Changing the Oil Filter

For replacement intervals, see the

Maintenance

chart.

1.  Drain the oil from the engine. See

Remove Oil

sec-

tion.

2.  Remove the oil filter (

C

, Figure 22) and dispose of

properly.

3.  Before you install the new oil filter, lightly lubricate the

oil filter gasket with fresh, clean oil.

4.  Install the oil filter by hand until the gasket contacts

the oil filter adapter, then tighten the oil filter 1/2 to 3/4
turns.

5.  Add oil. See

Add Oil

section.

6.  Start and run the engine. As the engine warms up,

check for oil leaks.

7.  Stop the engine and check the oil level. It should be at

the FULL mark on the dipstick.

Remove Oil

1.  With engine off but still warm, disconnect the spark

plug wire (

A

, Figure 21) and keep it away from the

spark plug.

2.  Remove the dipstick (

D

).

Standard Oil Drain Plug

1. Remove the oil drain plug (

B

, Figure 21). Drain the oil

into an approved container.

2.  After the oil has drained, install and tighten the oil

drain plug.

Optional Quick Oil Drain

1. Disconnect the oil drain hose (

G

, Figure 21) from the

side of the engine.

2.  Turn and remove the oil drain cap (

H

). Carefully lower

the quick oil drain (

I

) into an approved container (

J

).

3.  After the oil has drained, install the oil drain cap. At-

tach the oil drain hose to the side of the engine.

Add Oil

•  Place engine level.
•  Clean the oil fill area of any debris.
• See

the

Specifications

section for oil capacity.

1.  Remove the dipstick (

D

, Figure 21) and wipe with a

clean cloth.

2.  Pour the oil slowly into the engine oil fill (

E

).

Do not

overfill.

After adding oil, wait one minute and then

check the oil level.

3. Install and tighten the dipstick.
4.  Remove the dipstick and check the oil level. It should

be at the FULL mark (

F

) on the dipstick.

5.  Install and tighten the dipstick.
