OPERATION

WARNING

Mowing in reverse can be hazardous to bystanders.
Tragic accidents can occur if the operator is not
alert to the presence of children. Never activate
RMO if children are present. Children are often
attracted to the unit and the mowing activity.

DO NOT TOW

TRACTOR

Towing the unit will

cause transmission

damage. • Do not use

another vehicle to

push or pull this unit.

• Do not actuate the

transmission release

valve lever while the

engine is running.

Mowing in Reverse

If an operator chooses to mow in reverse, the RMO sys-
tem can be used.  To use the Reverse Mowing Option
(RMO) turn the RMO key after the PTO is engaged.  The
L.E.D. light will illuminate, and the operator can then mow
in reverse.  Each time the PTO is engaged the RMO needs
to be reactivated if desired.  The key should be removed to
restrict access to the RMO feature.

Pushing the Tractor by Hand

1. Disengage the PTO and turn the engine off.

2. Push the lever approximately 2-3/8” (6 cm) to release

the transmission (

A

, Figure 7).

3. The tractor can now be pushed by hand.

Emptying the Catcher

To empty the catcher:

1. Extend the catcher lever and push forward (

A

, Figure 9)

to empty the catcher (

B

).

2. Use the catcher lever to close the catcher, and slide it

back into the catcher.

Parking Brake Function

Applying the Parking Brake -

See Figure 8. To lock the

parking brake, release the ground speed pedals (

A

), fully

depress the brake pedal (

B

), pull UP on the parking brake

knob (

C

), and then release brake pedal.

Releasing the Parking Brake -

See Figure 8. To release

the parking brake, depress the brake pedal (

B

).

Cruise Control Operation

TO ENGAGE:

1. Pull up on the cruise control knob (

D

, Figure 8).

2. Depress the forward ground speed pedal (

A

).

3. Lift up the cruise control knob (

D

) when desired speed

is reached.  The Cruise will lock in one of its five locking
positions.

TO DISENGAGE:

1. Depress the brake pedal (

B

, Figure 8).

OR

2. Depress the forward ground speed pedal (

A

).

Hour Meter (if equipped)

The hour meter (

E

, Figure 8) measures the number of

hours the key has been in the RUN position.

Stopping the Tractor and Engine

1.  Return the ground speed control(s) to neutral.

2. Disengage the PTO and wait for all moving parts to stop.

3. Move the throttle control to SLOW position and turn the

ignition key (

D,

Figure 6) to OFF.  Remove the key.

23
