10

English

In case the brake is not e

ff

 ective, ask our dealer for inspection and

repairs.  If  the  engine  keeps  rotating  at  high  speed  with  the  brake
engaged, the clutch will overheat causing trouble.
When the brake engages during operation, immediately release the
throttle lever to stop the engine.

WARNING

Do not carr y the machine with the engine running.

Stopping

(Fig.

17)

Decrease engine speed, and push ignition switch (15) to stop
position.

WARNING

KICKBACK

DANGER

(Fig.

18)

One of the most severe dangers when working with a chain saw is
the possibility of kickback. Kickback may occur when the upper tip
of the guide bar touches an object, or when the wood closes in and
pinches the saw chain in the cut. Tip contact in some cases may
cause a lightning fast reverse reaction, kicking the guide bar up and
back toward you. Pinching the saw chain along the top of the guide
bar may also push the guide bar rapidly back towards you. Either of
these reactions may cause you to lose control of the saw which could
result in serious personal injur y. Even though your saw has safety
built into its design, you should not rely on these safety features
exclusively. Know where your bar tip is at all times. Kickback does
occur if you allow the kickback zone (19) of the bar to touch an object.
Do not use that area. Kickback from pinching is caused by a cut
closing and pinching the upper side of the guide bar. Study your cut
and make sure it will open as you cut through. Maintain control when
the engine is running by always keeping a

fi

 rm grip on the saw with

your right hand on the rear handle, your left hand on the front handle
and your thumbs and

fi

 ngers encircling the handles. Always hold the

saw with both hands during operation and cut at high engine speed.

WARNING

○

  Do not overreach or cut above shoulder height.

○

  Use extra caution when felling, and do not use the saw in a nose-

high position or above shoulder height.

CHAIN

CATCHER

The chain catcher is located on the power head just below the chain
to fur ther prevent the possibility of a broken chain striking the chain
saw user.

WARNING

Do not stand in-line with chain when cutting.

BASIC TECHNIQUES FOR MAKING FELLING, LIMBING AND
BUCKING CUTS
The intention of the following information is to provide you with the
general introduction to wood cutting techniques.

WARNING

○

  This information does not cover all speci

fi

 c situations, which

may depend on di

ff

 erences in terrain, vegetation, kind of wood,

form and size of trees, etc. Consult your ser vicing dealer,
forestr y agent or local forestr y schools for advice on speci

fi

 c

woodcutting  problems  in  your  area.  This  will  make  your  work
more e

ffi

  cient and safer.

○

  Avoid cutting in adverse weather conditions, such as dense fog,

heav y rain, bitter cold, high winds, etc.

Adverse weather is often tiring to work in and creates potentially
dangerous conditions such as slipper y ground.

High winds may force the tree to fall in an unexpected direction
causing proper ty damage or personal injur y.

CAUTION

Never use a chain saw to pr y or for any purpose for which it is not
intended.

WARNING

○

  Avoid stumbling on obstacles such as stumps, roots, rocks,

branches and fallen trees. Watch out for holes and ditches. Be
extremely cautious when working on slopes or uneven ground.

 Shut

o

ff

  the saw when moving from one work place to another.

Always cut at wide open throttle. A slow moving chain can easily
catch and force the saw to jerk.

○

  Never use the saw with only one hand.

You cannot control the saw properly and you may lose control
and injure yourself severely.

Keep the saw body close to your body to improve control and
reduce strain.

When cutting with the bottom par t of the chain the reactive force
will pull the saw away from you towards the wood you are cutting.

The saw will control the feeding speed and sawdust will be
directed towards you. (

Fig.

19

)

○

  When cutting with the upper par t of the chain the reactive force

will push the saw towards you and away from the wood you are
cutting. (

Fig.

20

)

○

  There is a risk of kickback if the saw is pushed far enough so that

you begin to cut with the nose of the bar.

The safest cutting method is to cut with the bottom par t of the
chain. Sawing with the upper par t makes it much more di

ffi

  cult to

control the saw and increases the risk of kickback.

○

  In case the chain locked, immediately release the throttle lever.

If the throttle lever keeps rotating at high speed with the chain
locked, the clutch will overheat causing trouble.

NOTE

Always keep the spiked bumper face to a tree, because the
chain may suddenly be drawn into a tree.

FELLING

Felling is more than cutting down a tree. You must also bring it down
as near to an intended place as possible without damaging the tree
or any thing else.
Before felling a tree, carefully consider all conditions which may
e

ff

 ect the intended direction, such as:

Angle of the tree. Shape of the crown. Snow load on the crown.
Wind conditions. Obstacles within tree range (e.g., other trees,
power lines, roads, buildings, etc.).

WARNING

○

  Always obser ve the general conditions of the tree. Look for

decay and rot in the trunk which will make it more likely to snap
and star t to fall before you expect it.

○

  Look for dr y branches, which may break and hit you when you

are working.

Always keep animals and people at least twice the tree length
away while felling. Clear away shrubs and branches from around
the tree.

Prepare a path of retreat away from the felling direction.

BASIC

RULES

FOR

FELLING

TREES

Normally the felling consists of two main cutting operations, notching
and making the felling cut. Star t making the upper notch cut on the
side of the tree facing the feeling direction. Look through the ker f as
you saw the lower cut so you do not saw too deep into the trunk. The
notch  should  be  deep  enough  to  create  a  hinge  of  su

ffi

  cient  width

and strength. The notch opening should be wide enough to direct
the fall of the tree as long as possible. Saw the felling cut from the
other side of the tree between one and two inches (3 – 5 cm) above
the edge of the notch. (

Fig.

21

)

20. Felling direction
21.  45° minimum notch opening
22. Hinge
23. Felling cut

Never saw completely through the trunk. Always leave a hinge.
The hinge guides the tree. If the trunk is completely cut through, you
lose control over the felling direction.
Inser t a wedge or a felling lever in the cut well before the tree
becomes unstable and star ts to move. This will prevent the guide
bar from binding in the felling cut if you have misjudged the falling
direction.  Make  sure  no  people  have  come  into  the  range  of  the
falling tree before you push it over.

FELLING

CUT,

TRUNK

DIAMETER

MORE

THAN

T WICE

GUIDE

BAR

LENGTH

Cut a large, wide notch. Then cut a recess into the center of the
notch. Always leave a hinge on both sides of the center cut. (

Fig.

22

)

Complete the felling cut by sawing around the trunk as in the

Fig.

23

.

WARNING

These methods are extremely dangerous because they involve
the use of the nose of guide bar and can result in kickback.

Only properly trained professionals should attempt these
techniques.
