English
1-9
190
173
61
310
61
Gas pipe end
Liquid pipe end
48
45
580
1065
219
40
40
91
45
Inside
Caulking
Outside
Wall embedded pipe
(Field supply)
Wall hole cover
(Field supply)
Wall embedded pipe
(Field supply)
Ø 65
Water Drainage Piping
The indoor drain pipe must be in a downward gradient for
smooth drainage. Avoid situations that are likely to cause
water to leak.
End dipped
into water
Water
leaking
Water
leaking
Water
leaking
Wrong
Wrong
Wrong
Drain
Water Drainage
Mounting plate
Clip
Mark (rear side)
Bottom frame
Front grille
Mount The Unit Onto The Installation Plate
Hook the indoor unit onto the upper portion of the installation
plate (Engage the two hooks at the rear top of the indoor unit
with the upper edge of the installation plate). Ensure that the
hooks are properly seated on the installation plate by moving
it to the left and right.
How To Attach The Indoor Unit
Hook the claws of the bottom frame to the mounting plate.
How To Remove The Indoor Unit
Push up the marked area (at the lower part of the front grille)
to release the claws.
Mounting plate
Interconnecting
wires
Hang indoor unit’s hook here.
Wire guide
When stripping the
ends of interconnecting
wires in advance, bind
right ends of wires with
insulating tape.
Through the
wall hole
Ø 65mm
Drain hose
position
Gas pipe end
Liquid pipe end
Recommended Mounting Plate Retention Spots And
Dimensions
166
184
181.7
55.5
54.5
153.8
263
51.9
800
45.9
42.2
288
42.2
45.9
Hole With Cone Drill
Water
Retention
All dimensions are in mm
Correct
50/60
20/35
!
CAUTION
• Do not install the unit at altitude over 2000m for both
indoor and outdoor.
©
Recommended mounting plate
retention spots (5 spots in all)
Use tape measure as shown.
Position the end of a tape measure at
f
Through the
wall hole
Ø 65mm
Drain hose
position
©
Recommended mounting plate retention spots
(7 spots in all)
Gas pipe end
Liquid pipe end
Through the
wall hole
Ø 65mm
Drain hose
position
Recommended mounting plate retention spots
(5 spots in all)
104
141
30
46
56
181
800
55
207
52
153
46
30
288
20/35 (ALTERNATIVE INSTALLATION PLATE)
All dimensions are in mm
All dimensions are in mm
