Safety Notes

Read and observe all instructions.
SAVE THESE INSTRUCTIONS FOR
FUTURE REFERENCE.

f

Have the measuring tool repaired only
through qualified specialists using original
spare parts.

This ensures that the safety of

the measuring tool is maintained.

Functional Description

Please unfold the fold-out page with the repre-
sentation of the measuring tool and leave it un-
folded while reading the operating instructions.

Intended Use

The measuring tool is intended for determining
and checking precise horizontal partitions. It is
also suitable for measuring heights, distances
and angles.

Product Features

The numbering of the product features shown
refers to the illustration of the measuring tool
on the graphic page.

1

Objective lens

2

Optical peep sight

3

Bubble vial mirror

4

Eyepiece cover

5

Adjusting screw for sighting line

6

Eyepiece

7

Circular bubble vial

8

Compensator lock

9

Horizontal circle reference mark

10

Horizontal circle

11

Adjusting screw of circular bubble vial

12

Levelling screw

13

Tripod mount 5/8"  (on the rear side)

14

Horizontal drive screw

15

Serial number

16

Focusing knob

17

Allen key

18

Adjusting pin

19

Case

20

Plumb-bob

The accessories illustrated or described are not in-
cluded as standard delivery.
