FBV MkII Advanced User Guide: POD X3

2•7

•  LOOP

 - (POD X3 Pro only) Toggles the FX Loop on/off.

•  DUAL

  -  Performs  the  same  toggling  behavior  between  Tone  1  and  Tone  2  as  the

TONE  2

(Hold For Dual)

 button on your POD X3 hardware, including the

Hold For Dual

 function to

enable/disable Dual Tone via footswitch.

Note:  You’ll  see  that  changing  to  the  DUAL  option  automatically  also  changes  the  TONE2  LP  SW
option to DUAL - this is necessary since both perform the same function.

TONE2 LP SW

(Shortboard only)

 - This LP SW  (“Loop Switch”) setting allows you to choose what

the FBV Shortboard FUNCTION2 switch actually controls for Tone1. Your options for Tone 1 are:

•  COMP

 - Toggles Compressor block On/Off.

•  AMP

 - Toggles Amp block On/Off.

•  LOOP

 - (POD X3 Pro only) Toggles the FX Loop On/Off.

•  DUAL

  -  Performs  the  same  toggling  behavior  between  Tone  1  and  Tone  2  as  the

TONE  2

(Hold For Dual)

 button, including the

Hold For Dual

 function to enable/disable Dual Tone via

footswitch.

TIP: Remember, these SYSTEM settings are specific to each User preset, so be sure to SAVE so that your
edited settings are retained for the particular preset you are modifying!

Using FBV Pedals with Tone 1 and Tone 2

Let’s take a look at the many options and behaviors available for using your FBV pedal (and optional

Expression  pedal)  with  Dual  Tone  presets.  As  described  above,  the  TONE1  and  TONE2  PEDAL

mode options (Wah/Volume/Tweak) provide independent pedal assignments per Tone, (as well as per

pedal,  if  you  have  FBV  Shortboard  with  an  optional  Expression  pedal  connected).  Therefore,  when

configuring these pedal options for a Preset, think about what you want to control in each Tone path.

Here are a some possibilities:

•  Controlling a Wah in Tone 1 or Tone 2 only
•  Controlling a Wah in both Tones simultaneously with a single pedal
•  Controlling a Wah in Tone 1 with pedal 1 and a Wah in Tone 2 independently with pedal 2
•  Controlling a Tweak parameter in Tone 1 or Tone 2 only
•  Controlling a common Tweak parameter in both Tones simultaneously with a single pedal
•  Controlling two different Tweak parameters in each Tone simultaneously with a single pedal
•  Controlling a Tweak parameter in Tone 1 with pedal 1 and different Tweak parameter in Tone

2 with pedal 2

When you have a Dual Tone preset loaded, and PEDAL CNTRL set to BOTH TONES with the

same

mode  settings  for  both  the  PEDAL  TONE1  and  PEDAL  TONE2,  then  this  FBV  pedal  and  its  toe

switch will actually control this same effect for both Tones

simultaneously

 (clever, eh?) For example,

if you choose “1-W/V” for both PEDAL TONE1 and PEDAL TONE2, then your onboard FBV pedal

will control the Wah or Volume effects for both Tones simultaneously. And clicking the toe switch will

also simultaneously toggle between the Wah & Volume for both Tones.*
