Product Description and Specifications

Read all safety warnings and all instruc-
tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire
and/or serious injury.

Intended Use

The power tool is intended as a stationary machine for making
straight lengthways and crossways cuts in wood. In this, hori-
zontal mitre angles from – 52 ° to +60 ° as well as vertical bevel
angles from 47 ° (leftward) to 47 ° (rightward) are possible.
The capacity of the power tool is designed for sawing hard-
wood and softwood.

The power tool is not suitable for cutting aluminium or other
non-ferrous metals or alloys.

Product Features

The numbering of the components shown refers to the repre-
sentation of the power tool on the graphic pages.

1

Dust bag

2

Hex key (1.5 mm)

3

Open-end spanner (17 mm; 10 mm)

4

Transport handle (front)

5

Clamp for handle

6

Tongue for grade-adjustment of handle

7

Handle

8

Button for releasing locking lever

43

9

Saw blade

10

Retracting blade guard

11

Roller

12

Insert plate

13

Locking bracket

14

Locking knob for various mitre angles

15

Mitre detent lever

16

Bevel lock lever

17

Detents for standard mitre angles

18

Saw table

19

Mounting holes

20

Fence

21

Fence extension

22

Locking screw for fence extension

23

Quick-action clamp

24

Angle indicator (vertical) for rightward bevel angle
range

25

Slide device

26

Cable holder

27

On/Off switch

28

Transport safety-lock

29

Adjusting screw of depth stop

30

Transport handle (rear)

31

Locking screw for slide device

32

Scale for bevel angle

33

Angle indicator (vertical) for leftward bevel angle
range

34

Adjustment knob for 33.9 ° bevel angle

35

Socket spanner (14 mm)/Hex key (4 mm)/Cross-head
screwdriver

36

Lock screw of the material stop

37

Material stop

38

Saw-table extension

39

Tensioning lever for saw-table extension

40

Scale for mitre angle

41

Rotary knob for adjustment of the bevel angle range

42

Spindle lock

43

Locking lever

44

Extraction adapter

45

Chip ejector

46/47

Cross-head screw (attachment of retracting blade
guard)

48

Hexagon bolt for saw-blade attachment

49

Washer

50

Clamping flange

51

Interior clamping flange

52

Holes for quick-action clamp

53

Clamping lever of the quick-action clamp

54

Threaded rod

55

Screws for insert plate

56

Clamping screw of the material stop

57

Button for rapid-setting of the adjusting screw

29

58

Depth stop

59

–

62

Set screws for 0 ° basic setting (bevel angle)

63

Set screw for 45 ° basic setting (leftward bevel angle)

64

Set screw for clamping force of lock lever

16

65

Set screw for clamping force of clamp

5

66

Mitre angle indicator

67

Adjustment screw of the fence extension

68

Hex socket screws (14 mm) of the fence

69

Recessed handles

Accessories shown or described are not part of the standard deliv-
ery scope of the product. A complete overview of accessories can
be found in our accessories program.
